Bianchi T-Tronik Rebel 9.2 – NX/SX EAGLE 2022
2022 E-bike
Estimate price |
5,890$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Travel Front 140mm -
Travel Rear 140mm -
Fork RockShox Recon Silver RL
-
Groupset NX Eagle, SX Eagle -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Darfon 630Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
T-Tronik Rebel 140mm alu 6061 triple butted, 1.5" tapered HT, seatpost diam. 31,6mm, seat clamp diam. 34.9mm, PM 160mm dropout thru axle 12x148mm, internal cable routing, sizes 38-43-48-53cm
Suspension Fork
Rock Shox Recon Silver RL 29B" Solo Air, 140mm
Rear Shock
Rock Shox Deluxe Select+ RL
Drivetrain
Rear Derailleur
SRAM NX Eagle 12sp
Shift Levers
SRAM SX Eagle 12sp
Cassette
SRAM PG1210 12sp, 11-50T
Crank
Fsa Forged Alu, crank length:165 mm w/34T Eagle chainring
Bottom Bracket
Included w/motor unit
Chain
SRAM SX Eagle 12sp
Wheels
Rear Hub
Formula CL-3248
Rims
WTB ST Light i30 TCS 2.0 29"
Tires
Kenda Hellkat 29x2.6
Brakes
Brakes
SRAM Guide T
Brake Levers
SRAM Guide T
Disk Rotors
SRAM Centerline, diam. 200mm
Cockpit
Stem
Tec Obvius, 0°, 1.1/8", diam. 31.8mm, ext: 55mm
Handlebar
Tec Obvius rise, AL6061-T6 double butted, width 780mm, diam. 31.8mm, 15mm rise, 9° backsweep
Grips
T-One Rock T-GP34
Headset
Fsa Orbit 1.5 ZS
Seat
Saddle
Velomann 2058DRN, 140mm width, Steel rails black, PVC soft touch
Seatpost
Dropper seatpost, diam 31.6mm, internal remote cable routing w/remote, travel: 100mm-15'', 125mm-17'', 150mm-19/21''
Motor & Battery
Motor
SHIMANO EP8 MOTOR UNIT W/DU-EP800 DRIVE UNIT, SPEED SENSOR
Battery
Darfon 630Wh
About this model
T-Tronik Rebel 9.2 – NX/SX EAGLE is part of the Bianchi E T Tronik model. Bianchi launched 37 e-bikes of this model so far. You can easily view all of the Bianchi E T Tronik e-bikes models from 2022, here.
Model range prices
Bianchi T-Tronik C-Type Sunrace X5 2022 is the most economical model, with a starting price of 2760$. Bianchi T-Tronik Performer 9.1 – XTR/XT 1X12 2022 on the other hand costs 8685$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail e-bikes average price
According to our calculations, the average cost of a Trail e-bike that is reliable is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
This e-bike was released in 2022 and its price was 5452$. In conclusion, this e-bike price is 62.02% higher than the price of the average Trail e-bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
T-Tronik Rebel 9.2 – NX/SX EAGLE components
Fork
The RockShox Recon Silver RL is included from the factory. It has a travel distance of 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Bianchi T-Tronik Rebel 9.2 – NX/SX EAGLE e-bike has the Rock Shox Deluxe Select+ RL model installed, and has a travel of 140mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
As for the wheels, Bianchi T-Tronik Rebel 9.2 – NX/SX EAGLE 2022, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Bianchi T-Tronik Rebel 9.2 – NX/SX EAGLE is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This e-bike has one size only, so it might not fit you. In conclusion, make sure it fits you, or look for another model.
Dropper post
Bianchi T-Tronik Rebel 9.2 – NX/SX EAGLE includes a dropper post. Therefore, climbing or descending will be a breeze.
