Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 140mm -
Fork RockShox Recon Silver RL
-
Groupset NX Eagle, SX Eagle -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Darfon 630Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
T-Tronik Rebel 140mm alu 6061 triple butted, 1.5" tapered HT, seatpost diam. 31,6mm, seat clamp diam. 34.9mm, PM 160mm dropout thru axle 12x148mm, internal cable routing, sizes 38-43-48-53cm
Suspension Fork
Rock Shox Recon Silver RL 29B" Solo Air, 140mm
Rear Shock
Rock Shox Deluxe Select+ RL
Drivetrain
Rear Derailleur
SRAM NX Eagle 12sp
Shift Levers
SRAM SX Eagle 12sp
Cassette
SRAM PG1210 12sp, 11-50T
Crank
Fsa Forged Alu, crank length:165 mm w/34T Eagle chainring
Bottom Bracket
Included w/motor unit
Chain
SRAM SX Eagle 12sp
Wheels
Rear Hub
Formula CL-3248
Rims
WTB ST Light i30 TCS 2.0 29"
Tires
Kenda Hellkat 29x2.6
Brakes
Brakes
SRAM Guide T
Brake Levers
SRAM Guide T
Cockpit
Stem
Tec Obvius, 0°, 1.1/8", diam. 31.8mm, ext: 55mm
Handlebar
Tec Obvius rise, AL6061-T6 double butted, width 780mm, diam. 31.8mm, 15mm rise, 9° backsweep
Grips
T-One Rock T-GP34
Headset
Fsa Orbit 1.5 ZS
Seat
Saddle
Velomann 2058DRN, 140mm width, Steel rails black, PVC soft touch
Seatpost
Dropper seatpost, diam 31.6mm, internal remote cable routing w/remote, travel: 100mm-15'', 125mm-17'', 150mm-19/21''
Motor & Battery
Motor
SHIMANO EP8 MOTOR UNIT W/DU-EP800 DRIVE UNIT, SPEED SENSOR
Battery
Darfon 630Wh
Model Overview
T-Tronik Rebel 9.2 NX/SX EAGLE belongs to the Bianchi E T Tronik model. There are 37 e-bikes that carry this model name. You can easily view all of the Bianchi E T Tronik e-bikes models from 2023, here.
Model range prices
Bianchi T-Tronik C-Type 2023 is the most economical model, with a starting price of 2700$. Bianchi T-Tronik Sport 9.1 Deore 2023 on the other hand costs 4350$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail e-bikes
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
This e-bike has the RockShox Recon Silver RL fork installed. The fork’s travel is 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
From the factory, it comes with the Rock Shox Deluxe Select+ RL rear shock model, which has a travel of 140mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When it comes to wheels, the T-Tronik Rebel 9.2 NX/SX EAGLE e-bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Bianchi T-Tronik Rebel 9.2 NX/SX EAGLE has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Bianchi T-Tronik Rebel 9.2 NX/SX EAGLE 2023 is available in one size only. In conclusion, double-check its size to make sure it’s a good fit for you.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
