Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork Suntour XCR Air
-
Groupset Deore, FSA -
Suspension Hardtail -
Motor Yamaha 250W mid-drive -
Battery SIMPLO, 36V, 630Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
E-TOURING SUV, ALLOY 6061, 29" Boost
Suspension Fork
SUNTOUR XCR34 Boost AIR 29", 15mm QR, TAPERED, 120mm TRAVEL
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M5100 SGS SHADOW PLUS DESIGN, 11-SPEED
Shift Levers
SHIMANO DEORE SL-M5100
Cassette
SHIMANO CS-M5100, 11-51 THEETH, 11-SPEED
Crank
FSA CK-320/ISIS, 34 TEETH
Chain
SHIMANO CN-HG901-11
Wheels
Front Hub
SHIMANO HB-MT410-B, 32 HOLES, 15x110mm BOOST THRU AXLE
Rear Hub
SHIMANO FH-MT400-B, 32 HOLES, 12x148mm BOOST THRU AXLE
Rims
ALEXRIMS EM-30, 32 HOLES, INNER WIDTH 30mm, 29"
Tires
SCHWALBE JONNY WATTS PERF. RACE GUARD, 292X2.35"
Brakes
Brakes
SHIMANO BR-MT400, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:203mm, R:180mm ROTORS
Brake Levers
SHIMANO BL-MT401
Cockpit
Stem
BIXS AS-M03, 0°ANGLE, 31.8mm CLAMP
Handlebar
BIXS HB-RB12W RIZER BAR, 760mm, 9°ANGLE, 25mm RISE, 31.8mm
Seat
Saddle
ERGON SFC30
Seatpost
BIXS SP-719, M: 350mm, OTHERS: 400mm, 31.6mm
Motor & Battery
Motor
YAMAHA PW-X 2 SERIES, 250 WATT
Battery
SIMPLO, 36V, 630Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
ACCESS-E20 FS is part of the Bixs E Access E20 model. There are 3 e-bikes that carry this model name. You can easily view all of the Bixs E Access E20 e-bikes models from 2023, here.
Model range prices
BiXS ACCESS-E20 GOR 2023 is the most affordable e-bike of this model and has a price of 4996$. On the other hand, BiXS ACCESS-E20 FS 2023, is the most expensive and costs 5775$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail e-bikes
According to our calculations, the average cost of a Trail e-bike that is reliable is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
This e-bike was released in 2023 and its price was 5775$. Comparing this to the average Trail e-bike price, we see that the price is 71.62% more expensive.
ACCESS-E20 FS components
Fork
The fork installed on this bike is the Suntour XCR Air model. The travel on this model is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
The ACCESS-E20 FS 2023 e-bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The ACCESS-E20 FS comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
