Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork Suntour NVX
-
Groupset Deore, Shimano -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery DARFON, 36V, 500Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eTOURING CONCEPT, ALLOY 6061, 700C
Suspension Fork
SUNTOUR NVX30, 700C, TAPERED, QR, 75MM TRAVEL
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M5120 SGS SHADOW PLUS DESIGN, 10-SPEED
Shift Levers
SHIMANO DEORE SL-M4100, WITH OPTICAL GEAR DISPLAY
Cassette
SHIMANO CS-M4100, 11-46 THEETH, 10-SPEED
Crank
SHIMANO STEPS FC-E6100, 38 TEETH
Bottom Bracket
STEPS, press-fit
Chain
SHIMANO CN-HG54
Pedals
VP 836
Wheels
Front Hub
SHIMANO HB-RM35, 32 HOLES, QR
Rear Hub
SHIMANO FH-RM35, 32 HOLES, QR
Rims
ALEXRIMS DM-21, 32 HOLES, INNER WIDTH 21mm, 700C
Tires
SCHWALBE ENERGIZER PLUS, PERFORMANCE, GREEN-GUARD ADDIX 700X55C
Brakes
Brakes
SHIMANO BR-MT200, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:180mm ROTORS
Brake Levers
SHIMANO BL-MT201
Cockpit
Stem
BIXS AS-4002, ANGLE ADJUSTABLE, 31.8mm CLAMP
Handlebar
BIXS HB-RB12L RIZER BAR, 720mm, 15°ANGLE, 15mm RISE, 31.8mm
Seat
Saddle
BIXS VL-3534
Seatpost
BIXS SP-3D2, 48cm: 350mm, OTHERS: 400mm, 31.6mm
Motor & Battery
Motor
SHIMANO STEPS DU-E6100, 250 WATT
Battery
DARFON, 36V, 500Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
CAMPUS-E40 belongs to the Bixs E Campus E40 model. There are 3 e-bikes that carry this model name. You can easily view all of the Bixs E Campus E40 e-bikes models from 2023, here.
Model range prices
BiXS CAMPUS-E40 GOR 2023 is the most economical model, with a starting price of 3995$. BiXS CAMPUS-E40 DI 2023 on the other hand costs 3995$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Commuter e-bikes average price
If you want to purchase a solid Commuter e-bike, it is important to know that the average cost is 2569$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Commuter e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, BiXS CAMPUS-E40 price was 3995$. Doing a quick comparison, we notice that CAMPUS-E40 price is 55.51% higher than the average cost of a Commuter e-bike.
Overview of components
Fork
The Suntour NVX is included from the factory. It has a travel distance of 75mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When leaving the production line, the CAMPUS-E40 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. BiXS CAMPUS-E40 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
