Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox Revelation RC
-
Groupset Deore, Shimano -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TRAIL GEOMETRY, FULL CARBON FRAME, 140MM TRAVEL, DROPOUT 148X12MM BOOST, 29"
Suspension Fork
ROCK SHOX REVELATION RC, 15X110MM AXLE, TAPERED, 150MM TRAVEL, REBOUND, COMPRESSION TO LOCK
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M6100 SGS SHADOW PLUS DESIGN, 12-SPEED
Shift Levers
SHIMANO DEORE SL-M6100, CLAMP TYPE
Cassette
SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED
Crank
SHIMANO FC-MT512, 2-PIECE CRANKSET, S: 30 THEETH, OTHERS 32 TEETH
Chain
SHIMANO CN-M6100 12-SPEED
Wheels
Front Hub
SUNRINGLE WHEELSET DUROC 30 COMP, 32 HOLES, 15x110mm THRU AXLE
Rear Hub
SUNRINGLE WHEELSET DUROC 30 COMP, 32 HOLES, 12x148mm BOOST, THRU AXLE
Rims
SUNRINGLE WHEELSET DUROC 30 COMP, TLR, 32 HOLES, INNER WIDTH 27mm, 29"
Tires
ONZA IBEX, KEVLAR FOLDABLE, TUBELESS READY, 29X2.4"
Brakes
Brakes
SHIMANO BR-MT500, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:180mm ROTORS
Brake Levers
SHIMANO BL-MT501
Cockpit
Stem
BIXS 0°ANGLE, 35mm CLAMP
Handlebar
BIXS RIZER BAR, 780mm, 9° BACKSWEEP, 15mm RISE, 35mm
Seat
Saddle
BiXS VL-1831
Seatpost
KIND SHOCK RAGE- I, S: 100MM, M: 125MM, L: 150MM, XL: 170MM TRAVEL, SHIMANO REMOTE, 31.6MM
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
PEAK 340 completes the Bixs Peak model. BiXS launched 3 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
BiXS PEAK 340 2023 is the most economical model, with a starting price of 4551$. BiXS PEAK 140 2023 on the other hand costs 7778$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2023 and its price was 4551$. In conclusion, this bike price is 64.77% more expensive than the price of the average Trail bike.
PEAK 340 components
Fork
BiXS PEAK 340 2023 bike is equipped with the RockShox Revelation RC fork, and has 150mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
When leaving the production line, the PEAK 340 model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. BiXS PEAK 340 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
