Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Performance Float 34
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TRAIL GEOMETRY, CARBON, ALLOY ROCKER. 120mm TRAVEL, 29"
Suspension Fork
FOX 34 FLOAT PERFORMANCE 29", 15x110mm AXLE, TAPERED, GRIP, TRAVEL: 130mm, 3-POSITION LEVER
Drivetrain
Rear Derailleur
SHIMANO XT RD-M8100 SGS SHADOW PLUS DESIGN, 12-SPEED
Shift Levers
SHIMANO XT SL-M8100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV
Cassette
SHIMANO CS-M8100, 10-51 THEETH, 12-SPEED
Crank
SHIMANO XT FC-M8100-1, HOLLOWTECH II, 32 TEETH
Bottom Bracket
BSA, 73mm, threaded
Chain
SHIMANO CN-M8100 12-SPEED
Wheels
Front Hub
DT SWISS WHEELSET SPLINE XM-1700, 28 HOLES, 15mm THRU AXLE
Rear Hub
DT SWISS WHEELSET SPLINE XM-1700, 28 HOLES, 12x148mm BOOST, THRU AXLE
Rims
DT SWISS WHEELSET SPLINE XM-1700, 28 HOLES, 30MM INNER WIDTH 29"
Tires
ONZA PORCUPINE, KEVLAR FOLDABLE, TUBELESS READY, 29X2.40"
Brakes
Brakes
SHIMANO XT BR-M8120, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:180mm, R:180mm ROTORS, ICE TECH
Brake Levers
SHIMANO XT BL-M8100, ISPEC EV
Cockpit
Stem
RACE FACE TURBINE R, 0°ANGLE, 35mm CLAMP
Handlebar
RACE FACE TURBINE 35, 760mm, 20mm RISE, 8° BACKSWEEP, 35mm
Seat
Saddle
ERGON SM10 SPORT MAN
Seatpost
KIND SHOCK LEV SI, M & L: 125MM, XL: 150MM TRAVEL, SHIMANO REMOTE LEVER, 31.6MM
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
SIGN 120 is a Bixs Sign model. BiXS launched 9 bikes of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
BiXS SIGN 520 2023 is the cheapest bike model and costs 3105$. BiXS SIGN X 2023 is the most expensive one and costs 10338$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2023 for 6332$. In conclusion, this bike price is 129.25% more expensive than the price of the average Trail bike.
Overview of components
Fork
The SIGN 120 comes factory-installed with the Fox Performance Float 34 fork. This has a travel range of 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When it comes to wheels, the SIGN 120 bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The SIGN 120 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
