Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Pike Select
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TRAIL GEOMETRY, ALLOY 6061, 120MM TRAVEL, DROPOUT FOR 148X12MM BOOST, 29"
Suspension Fork
ROCK SHOX PIKE SELECT CHARGER, 15X110MM AXLE, TAPERED, 130MM TRAVEL, REBOUND, COMPRESSION
Drivetrain
Rear Derailleur
SHIMANO XT RD-M8100 SGS SHADOW PLUS DESIGN, 12-SPEED
Shift Levers
SHIMANO XT SL-M8100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV
Cassette
SHIMANO CS-M8100, 10-51 THEETH, 12-SPEED
Crank
SHIMANO XT FC-M8100-1, HOLLOWTECH II, 32 TEETH
Bottom Bracket
BSA, 73mm, threaded
Chain
SHIMANO CN-M8100 12-SPEED
Wheels
Front Hub
DT SWISS WHEELSET SPLINE XM-1700, 28 HOLES, 15mm THRU AXLE
Rear Hub
DT SWISS WHEELSET SPLINE XM-1700, 28 HOLES, 12x148mm BOOST, THRU AXLE
Rims
DT SWISS WHEELSET SPLINE XM-1700, 28 HOLES, 30MM INNER WIDTH 29"
Tires
ONZA PORCUPINE, KEVLAR FOLDABLE, TUBELESS READY, 29X2.40"
Brakes
Brakes
SHIMANO XT BR-M8120, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:180mm, R:180mm ROTORS, ICE TECH
Brake Levers
SHIMANO XT BL-M8100, ISPEC EV
Cockpit
Stem
FSA NS ICR STEM, 10° ANGLE, 31.8MM CLAMP
Handlebar
RACE FACE TURBINE, 760MM, 0.5" RSIER WIDE, 31.8MM
Seat
Saddle
BIXS VL-1A85
Seatpost
KIND SHOCK LEV SI, S: 100MM, M & L: 125MM, TRAVEL, SOUTHPAW REMOTE LEVER, 31.6MM
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
SIGN 320 MARIPOSA belongs to the Bixs Sign model. 9 bikes variations carry this model name so far. You can easily view all of the Bixs Sign bikes models from 2023, here.
Model range prices
BiXS SIGN 520 2023 is the most economical model, with a starting price of 3105$. BiXS SIGN X 2023 on the other hand costs 10338$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4996$. Comparing the average cost of a Trail bike to this one, you will see that SIGN 320 MARIPOSA price is 80.88% more expensive.
Overview of components
Fork
The fork installed on this bike is the RockShox Pike Select model. The travel on this model is 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
The wheels on SIGN 320 MARIPOSA are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The SIGN 320 MARIPOSA comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
BiXS SIGN 320 MARIPOSA bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
