Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Al-13 Butted, Hydroformed aluminum
Suspension Fork
Alpenchallenge AC02, Al-13 aluminum
Rear Shock
-
Drivetrain
Rear Derailleur
Shimano Tiagra
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra, Rapidfire Plus
Cassette
Shimano Tiagra, 11-34
Crank
Shimano Tiagra, 50-39-30T
Chain
KMC X10
Wheels
Front Hub
Shimano M4050
Rear Hub
Shimano M4050
Rims
DT SWISS R522D
Tires
Continental Sport Contact II, 35mm
Brakes
Brakes
Shimano M506/M506 / RT54 rotors (160/160)
Cockpit
Stem
BMC LSM 03
Handlebar
BMC LSB 03
Seat
Saddle
Selle Royal Sirio
Seatpost
BMC LSP 03
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.4 mm | 1.42 mm | 1.46 mm |
| Front Center | 608 mm | 637 mm | 654 mm | 682 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 68 mm | 68 mm | 68 mm | 68 mm |
| Stack | 536 mm | 577 mm | 597 mm | 636 mm |
| Reach | 396 mm | 411 mm | 421 mm | 436 mm |
| Top Tube Length | 558 mm | 591 mm | 607 mm | 640 mm |
| Seat Tube Angle | 73 ° | 72.5 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 440 mm | 510 mm | 560 mm | 610 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 122 mm | 165 mm | 187 mm | 228 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1045 mm | 1074 mm | 1091 mm | 1119 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 746 mm | 803 mm | 834 mm | 869 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
alpenchallenge AC02 is part of the Bmc Alpenchallenge model. BMC launched 46 bikes of this model so far. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
The most economical model, the BMC alpenchallenge AC02 2017 has a starting price of 1399$. BMC alpenchallenge AC01 IGH 2017 on the other hand is the most expensive at 2699$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Commuter bikes average price
If you want an acceptable Commuter bike you should know that the average price is 762$. However, you could also get a good Commuter bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2017 and its price was 1399$. Doing a quick comparison, we notice that alpenchallenge AC02 price is 83.6% more expensive than the average cost of a Commuter bike.
alpenchallenge AC02 components
Fork material
The fork is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
The wheels on alpenchallenge AC02 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The alpenchallenge AC02 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
BMC alpenchallenge AC02 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
