Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Force -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ACE Technology, 01 Premium Carbon, Tuned Compliance Concept
Suspension Fork
TCC 01 Premium Carbon Compliance-Fork, Disc-specific
Drivetrain
Rear Derailleur
SRAM Force CX1
Front Derailleur
-
Shift Levers
SRAM Force HRD
Cassette
SRAM PG1170, 11-32T
Crank
SRAM Force CX1, 40T
Chain
SRAM PC1130
Wheels
Front Hub
DT Swiss R23 Spline, 6-Bolt
Rear Hub
DT Swiss R23 Spline, 6-Bolt
Rims
DT Swiss R23 Spline
Tires
Vittoria Terreno Dry, 33mm
Brakes
Brakes
SRAM Force HRD-A1 / Centerline (140/140)
Cockpit
Stem
BMC RSM 03
Handlebar
BMC RAB 03, ergo top shape, compact bend
Seat
Saddle
Fizik Antares R7, manganese
Seatpost
TCC 01 Premium Carbon Compliance-Post, 3mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 57cm | 60cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.4 mm | 1.42 mm | 1.44 mm | 1.48 mm |
| Bottom Bracket Height | 282 mm | 282 mm | 282 mm | 282 mm | 282 mm |
| Front Center | 576 mm | 580 mm | 591 mm | 605 mm | 625 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 76 mm | 66 mm | 63 mm | 63 mm | 63 mm |
| Stack | 513 mm | 537 mm | 557 mm | 579 mm | 608 mm |
| Reach | 375 mm | 384 mm | 393 mm | 401 mm | 412 mm |
| Top Tube Length | 525 mm | 541 mm | 556 mm | 570 mm | 590 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 475 mm | 505 mm | 535 mm | 565 mm | 600 mm |
| Head Tube Angle | 70.5 ° | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 108 mm | 128 mm | 148 mm | 171 mm | 201 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1001 mm | 1004 mm | 1015 mm | 1029 mm | 1050 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm |
| Standover Height | 742 mm | 770 mm | 803 mm | 820 mm | 852 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
Crossmachine CX01 ONE is part of the Bmc Crossmachine model. 6 bikes variations carry this model name so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
BMC Crossmachine CXA01 Rival 2018 is the most affordable bike of this model and has a price of 2299$. On the other hand, BMC Crossmachine CX01 ONE 2018, is the most expensive and costs 4299$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Cyclocross bikes average price
If you want an acceptable Cyclocross bike you should know that the average price is 2012$. However, even if your budget is less than the average, you might still be able to get a top-quality Cyclocross bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, BMC Crossmachine CX01 ONE price was 4299$. Comparing this to the average Cyclocross bike price, we see that the price is 113.67% more expensive.
Crossmachine CX01 ONE components
Fork material
Crossmachine CX01 ONE has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When leaving the production line, the Crossmachine CX01 ONE model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. BMC Crossmachine CX01 ONE has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
