Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork Fox Factory Float 32
-
Groupset XX1 Eagle AXS, SRAM -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
171cm - 182cm
LG
180cm - 189cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fourstroke 01 Premium Carbon with Autodrop Technology, APS Suspension System 100mm Travel, Fully Guided Internal Cable Routing, PF92 Bottom Bracket, Post Mount Disc, 12x148mm Boost Thru-Axle
Suspension Fork
Fox Float 32 SC Factory Fork
Rear Shock
Fox Float DPS Factory Shock
Drivetrain
Rear Derailleur
SRAM XX1 AXS Eagle
Shift Levers
SRAM AXS Controller
Cassette
SRAM XX1 XG-1299 Eagle 10-52T
Crank
SRAM XX1 Eagle Carbon 34T
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM XX1 Eagle
Wheels
Front Hub
DT Swiss 180 Straightpull. Ratchet EXP 36
Rear Hub
DT Swiss 180 Straightpull. Ratchet EXP 36
Rims
DT Swiss XRC 1200 Wheelset. 30mm Inner Width
Tires
Vittoria Mezcal 2.35"
Brakes
Brakes
SRAM Level Ultimate | SRAM HS2 (160/160 S-M. 180/160 L-XL)
Cockpit
Stem
BMC MSM01
Handlebar
BMC MFB01 Carbon 760mm
Seat
Saddle
Prologo Dimension NDR T4.0
Seatpost
BMC Autodrop Integrated Dropper Seatpost, 80mm Drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.33 mm | 1.29 mm | 1.26 mm | 1.23 mm |
| Bottom Bracket Height | 321 mm | 321 mm | 321 mm | 321 mm |
| Front Center | 712 mm | 744 mm | 761 mm | 791 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 113 mm | 113 mm | 113 mm | 113 mm |
| Stack | 587 mm | 595 mm | 603 mm | 618 mm |
| Reach | 440 mm | 460 mm | 480 mm | 503 mm |
| Top Tube Length | 577 mm | 600 mm | 624.2 mm | 652.23 mm |
| Seat Tube Angle | 76.7 ° | 76.7 ° | 76.7 ° | 76.7 ° |
| Seat Tube Length | 420 mm | 440 mm | 470 mm | 510 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 83.84 mm | 93.5 mm | 101.25 mm | 117.58 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1142 mm | 1174 mm | 1191 mm | 1221 mm |
| Bottom Bracket Drop | 53 mm | 53 mm | 53 mm | 53 mm |
| Standover Height | 728 mm | 728 mm | 728 mm | 728 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Max Height | 173 cm | 182 cm | 189 cm | cm |
Model Overview
Fourstroke 01 LTD is part of the Bmc Fourstroke model. 41 bikes variations carry this model name so far. You can easily view all of the Bmc Fourstroke bikes models from 2023, here.
Model range prices
BMC Fourstroke FOUR 2023 is the most affordable bike of this model and has a price of 4699$. On the other hand, BMC Fourstroke 01 LTD 2023, is the most expensive and costs 13499$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 13499$. Comparing the average cost of a Crosscountry bike to this one, you will see that Fourstroke 01 LTD price is 608.61% more expensive.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Fourstroke 01 LTD components
Fork
The Fourstroke 01 LTD comes factory-installed with the Fox Factory Float 32 fork. This has a travel range of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The Fourstroke 01 LTD has a rear shock with a travel of 100mm. The model Fox Float DPS Factory Shock is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When it comes to wheels, the Fourstroke 01 LTD bike is equipped with the 29″ carbon model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Fourstroke 01 LTD comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Dropper post
The BMC model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
