Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork DT Swiss
-
Groupset XX SL Eagle Transmission, SRAM -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
171cm - 182cm
LG
180cm - 189cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fourstroke 01 Premium Carbon with Autodrop Technology | APS Suspension System, 100mm Travel- Fully Guided Internal Cable Routing | PF92 Bottom Bracket | Post Mount Disc | 12x148mm Boost Thru-Axle
Suspension Fork
Fox Float 34 SC Factory | Kashima Coating | DT Swiss Remote Lockout
Rear Shock
Fox Float DPS EVOL LV Factory Shock
Drivetrain
Rear Derailleur
SRAM XX SL Eagle Transmission
Shift Levers
SRAM AXS Pod Controller
Cassette
SRAM XX SL Eagle Transmission 10-52T (XS-1299)
Crank
SRAM XX SL Eagle Carbon 34T
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM XX SL Eagle Transmission Flattop
Wheels
Front Hub
DT Swiss 180 Straightpull, Ratchet EXP 36
Rear Hub
DT Swiss 180 Straightpull, Ratchet EXP 36
Rims
DT Swiss XRC 1200 Wheelset, 30mm Inner Width
Tires
Vittoria Mezcal 2.35"
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
BMC MSM01
Handlebar
BMC MFB01 Carbon 760mm
Seat
Saddle
Prologo Dimension NDR
Seatpost
BMC Autodrop Integrated Dropper Seatpost - 80mm Drop
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.336 mm | 1.295 mm | 1.258 mm | 1.23 mm |
| Bottom Bracket Height | 321 mm | 321 mm | 321 mm | 321 mm |
| Front Center | 714 mm | 738 mm | 762 mm | 791 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 113 mm | 113 mm | 113 mm | 113 mm |
| Stack | 584 mm | 592 mm | 600 mm | 615 mm |
| Reach | 437 mm | 457 mm | 477 mm | 500 mm |
| Top Tube Length | 574 mm | 597 mm | 621.2 mm | 649.23 mm |
| Seat Tube Angle | 76.7 ° | 76.7 ° | 76.7 ° | 76.7 ° |
| Seat Tube Length | 420 mm | 440 mm | 470 mm | 510 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 83.84 mm | 93.5 mm | 101.25 mm | 117.58 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1139 mm | 1171 mm | 1188 mm | 1218 mm |
| Bottom Bracket Drop | 53 mm | 53 mm | 53 mm | 53 mm |
| Standover Height | 725 mm | 725 mm | 725 mm | 725 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Max Height | 173 cm | 182 cm | 189 cm | cm |
About this model
Fourstroke 01 LTD is a Bmc Fourstroke model. BMC released 52 bikes variations of this model so far. Take a sneak peek at all Bmc Fourstroke bikes models from 2024, by clicking here.
Model range prices
BMC Fourstroke FOUR 2024 is the most affordable bike of this model and has a price of 4870$. On the other hand, BMC Fourstroke 01 LTD 2024, is the most expensive and costs 14824$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When BMC released this model in 2024, its price was 14824$. In conclusion, this bike price is 678.16% higher than the price of the average Crosscountry bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
BMC Fourstroke 01 LTD 2024 bike is equipped with the DT Swiss fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
BMC Fourstroke 01 LTD bike has the Fox Float DPS EVOL LV Factory Shock model installed, and has a travel of 100mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
When leaving the production line, the Fourstroke 01 LTD model has 29″ carbon wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Dropper post
A dropper post is included with the Fourstroke 01 LTD. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
