Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED XPLR eTap, RED AXS -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
51cm
165cm - 174cm
54cm
172cm - 180cm
56cm
178cm - 186cm
58cm
184cm - 192cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kaius 01 Premium Carbon with Aerocore Design | ICS Technology, Stealth Cable Routing | Integrated Aerocore Bottle Cages | Stealth Dropout Design | TCC Race Compliance Level | PF86 Bottom Bracket | Flat Mount Disc | 12x142mm Thru-Axle
Suspension Fork
Kaius 01 Premium Carbon | ICS Technology, Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc | 12x100mm Thru-Axle
Drivetrain
Rear Derailleur
SRAM RED AXS XPLR
Shift Levers
SRAM RED eTap AXS HRD
Cassette
SRAM XPLR XG-1271 10-44T
Crank
SRAM RED AXS 1 DUB WIDE 42T Power Meter
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM RED 12 Speed
Wheels
Front Hub
Zipp 303 Firecrest
Rear Hub
Zipp 303 Firecrest
Rims
Zipp 303 Firecrest
Tires
Pirelli Cinturato Gravel H, 40mm
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
ICS Carbon Evo, One-Piece Full Carbon Cockpit
Handlebar
ICS Carbon Evo - One Piece Full Carbon Cockpit
Seat
Saddle
Fizik Vento Argo R1 - 140mm
Seatpost
Kaius 01 Premium Carbon D-Shaped Seatpost | 15mm Offset | D-Fender Compatible
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.308 mm | 1.335 mm | 1.372 mm | 1.407 mm | 1.451 mm | 1.498 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 596 mm | 610 mm | 608 mm | 619 mm | 632 mm | 644 mm |
| Rake | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 66 mm | 66 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Stack | 510 mm | 530 mm | 550 mm | 570 mm | 595 mm | 620 mm |
| Reach | 390 mm | 397 mm | 401 mm | 405 mm | 410 mm | 414 mm |
| Top Tube Length | 546 mm | 559 mm | 569 mm | 579 mm | 592 mm | 604 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 428 mm | 452 mm | 468 mm | 493 mm | 513 mm | 533 mm |
| Head Tube Angle | 71 ° | 71 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 85 mm | 106 mm | 123 mm | 144 mm | 170 mm | 196 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1003 mm | 1017 mm | 1015 mm | 1026 mm | 1039 mm | 1051 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 684 mm | 722 mm | 756 mm | 780 mm | 798 mm | 818 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 167 cm | 174 cm | 180 cm | 186 cm | 192 cm | cm |
Model Overview
Kaius 01 LTD is a Bmc Kaius model. There are 6 bikes that carry this model name. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
BMC Kaius 01 THREE 2024 is the most economical model, with a starting price of 6352$. BMC Kaius 01 LTD 2024 on the other hand costs 12706$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2024 and its price was 12706$. Comparing this to the average Gravel bike price, we see that the price is 416.08% more expensive.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The Kaius 01 LTD 2024 bike is equipped with 700c carbon wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. BMC Kaius 01 LTD is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
