Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
51cm
165cm - 174cm
54cm
172cm - 180cm
56cm
178cm - 186cm
58cm
184cm - 192cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kaius 01 Premium Carbon with Aerocore Design, ICS Technology Stealth Cable Routing, Integrated Aerocore Bottle Cages, Stealth Dropout Design, TCC Race Compliance Level, PF86 Bottom Bracket, Flat Mount Disc, 12x142mm Thru-Axle
Suspension Fork
Kaius 01 Premium Carbon, ICS Technology, Stealth Cable Routing, TCC Race Compliance Level, Stealth Dropout Design, Flat Mount Disc, 12x100mm Thru-Axle
Drivetrain
Rear Derailleur
SRAM FORCE eTap AXS WIDE
Shift Levers
SRAM FORCE eTap AXS HRD
Cassette
SRAM FORCE AXS XG-1270 10-36T
Crank
SRAM FORCE AXS WIDE 43-30T
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM FORCE 12 Speed
Wheels
Front Hub
Zipp 303 S
Rear Hub
Zipp 303 S
Rims
Zipp 303 S
Tires
Pirelli Cinturato Gravel H - 40mm
Brakes
Brakes
SRAM Force eTap AXS HRD | SRAM Centerline X Rotors 160 / 160mm
Cockpit
Stem
BMC ICS2 - Integrated Cockpit Design
Handlebar
BMC RCB01 Carbon. Ergo Top Shape. Compact Bend
Seat
Saddle
Fizik Vento Argo R3
Seatpost
Kaius 01 Premium Carbon D-Shaped Seatpost, 15mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.31 mm | 1.34 mm | 1.38 mm | 1.41 mm | 1.46 mm | 1.5 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 596 mm | 610 mm | 608 mm | 619 mm | 632 mm | 644 mm |
| Rake | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 66 mm | 66 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Stack | 504 mm | 524 mm | 544 mm | 564 mm | 589 mm | 614 mm |
| Reach | 384 mm | 391 mm | 395 mm | 399 mm | 404 mm | 408 mm |
| Top Tube Length | 540 mm | 553 mm | 563 mm | 573 mm | 586 mm | 598 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 428 mm | 452 mm | 468 mm | 493 mm | 513 mm | 533 mm |
| Head Tube Angle | 71 ° | 71 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 85 mm | 106 mm | 123 mm | 144 mm | 170 mm | 196 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheelbase | 997 mm | 1011 mm | 1009 mm | 1020 mm | 1033 mm | 1045 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 678 mm | 716 mm | 750 mm | 774 mm | 792 mm | 812 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 167 cm | 174 cm | 180 cm | 186 cm | 192 cm | cm |
Model Overview
Kaius 01 TWO completes the Bmc Kaius model. There are 3 bikes that carry this model name. Take a sneak peek at all Bmc Kaius bikes models from 2023, by clicking here.
Model range prices
BMC Kaius 01 THREE 2023 is the most economical model, with a starting price of 5999$. BMC Kaius 01 ONE 2023 on the other hand costs 11999$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When BMC released this model in 2023, its price was 8999$. If we compare this with the average Gravel bike cost we notice that the price is 265.52% higher.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork material
Kaius 01 TWO has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The wheels on Kaius 01 TWO are the 700c carbon type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. BMC Kaius 01 TWO is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
