Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
51cm
165cm - 174cm
54cm
172cm - 180cm
56cm
178cm - 186cm
58cm
184cm - 192cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Roadmachine 01 Premium Carbon with Tuned Compliance Concept Endurance, • ICS Technology, Stealth Cable Routing, • PF86 Bottom Bracket, • Integrated Seatpost Clamp, • Flat Mount Disc, • 12x142mm Thru-Axle
Suspension Fork
Roadmachine 01 Premium Carbon with Tuned Compliance Concept Endurance, • ICS Technology, Stealth Cable Routing, • Flat Mount Disc, • 12x100mm Thru-Axle, • 50mm Offset (Size 47-51), 45mm Offset (Size 54-61)
Drivetrain
Rear Derailleur
SHIMANO Ultegra Di2
Front Derailleur
SHIMANO Ultegra Di2
Shift Levers
SHIMANO Ultegra Di2
Cassette
SHIMANO Ultegra 11-34T
Crank
SHIMANO Ultegra 50-34T
Bottom Bracket
BB86/BB92, press-fit
Chain
SHIMANO Ultegra
Wheels
Front Hub
DT Swiss 240 Straightpull, Ratchet SyStem 36 SL
Rear Hub
DT Swiss 240 Straightpull, Ratchet SyStem 36 SL
Rims
DT Swiss ERC 1400 DICUT, 45mm
Tires
Vittoria Corsa Control, 28mm
Brakes
Brakes
SHIMANO Ultegra, RT-MT800 Rotors (160/140)
Cockpit
Stem
BMC ICS2 - Integrated Cockpit Design
Handlebar
BMC RCB01 Carbon, Ergo Top Shape, Compact Bend
Seat
Saddle
Fizik Argo Tempo R5 (150mm)
Seatpost
Roadmachine 01 Premium Carbon D-Shaped Seatpost, • 15mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.41 mm | 0.306 mm | 1.5 mm | 1.54 mm | 1.61 mm |
| Bottom Bracket Height | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm |
| Front Center | 583 mm | 599 mm | 597 mm | 609 mm | 621 mm | 635 mm |
| Rake | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm |
| Stack | 519 mm | 544 mm | mm | 589 mm | 613 mm | 647 mm |
| Reach | 377 mm | 385 mm | 565 mm | 393 mm | 397 mm | 401 mm |
| Top Tube Length | 525 mm | 535 mm | 549 mm | 559 mm | 571 mm | 586 mm |
| Seat Tube Angle | 74.2 ° | 74.2 ° | 74.2 ° | 74.2 ° | 74.2 ° | 74.2 ° |
| Seat Tube Length | 420 mm | 457 mm | 500 mm | 522 mm | 539 mm | 573 mm |
| Head Tube Angle | 71.2 ° | 71.2 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 112 mm | 139 mm | 156 mm | 181 mm | 206 mm | 242 mm |
| Chainstay Length | 413 mm | 413 mm | 413 mm | 413 mm | 413 mm | 413 mm |
| Wheelbase | 985 mm | 1002 mm | 1000 mm | 1011 mm | 1023 mm | 1038 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 167 cm | 174 cm | 180 cm | 186 cm | 192 cm | cm |
Model Overview
Roadmachine 01 THREE belongs to the Bmc Roadmachine model. 95 bikes variations carry this model name so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
BMC Roadmachine X AL, ONE 2022 is the most economical model, with a starting price of 2441$. BMC Roadmachine 01, ONE P2P 2022 on the other hand costs 12456$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Endurance bikes average price
If you want to purchase a solid Endurance bike, it is important to know that the average cost is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2022 and its price was 8499$. Doing a quick comparison, we notice that Roadmachine 01 THREE price is 262.28% higher than the average cost of an Endurance bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
As for the wheels, BMC Roadmachine 01 THREE 2022, has a 700c carbon model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. BMC Roadmachine 01 THREE is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
