Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
47cm
152cm - 168cm
51cm
166cm - 174cm
54cm
172cm - 180cm
56cm
177cm - 186cm
58cm
183cm - 192cm
61cm
187cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TCC 02 Carbon, Angle Compliance Technology
Suspension Fork
Roadmachine 02 Carbon, Disc-specific
Drivetrain
Rear Derailleur
Shimano Ultegra Di2
Front Derailleur
Shimano Ultegra Di2
Shift Levers
Shimano Ultegra Di2, Hydraulic
Cassette
Shimano Ultegra, 11-30T
Crank
Shimano Ultegra, 50-34T
Chain
Shimano Ultegra
Wheels
Front Hub
3T Discus C35 Pro, Thru Axle (12mm)
Rear Hub
3T Discus C35 Pro, Thru Axle (12mm)
Rims
3T Discus C35 Pro
Tires
Vittoria Rubino Pro, 28mm
Brakes
Brakes
Shimano Ultegra Di2, SM-RT800 Rotors (160/140)
Cockpit
Stem
BMC RSM01, w/ computer and camera mount
Handlebar
BMC RAB 02, ergo top shape, compact bend
Seat
Saddle
Selle Royal 2075 HRN
Seatpost
Roadmachine 01 "D" Premium Carbon, 15mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.42 mm | 1.44 mm | 1.46 mm | 1.48 mm | 1.51 mm |
| Bottom Bracket Height | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm |
| Front Center | 583.7 mm | 595 mm | 597 mm | 608 mm | 622 mm | 636 mm |
| Rake | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm |
| Stack | 517 mm | 542 mm | 563 mm | 577 mm | 596 mm | 620 mm |
| Reach | 378 mm | 381 mm | 390 mm | 396 mm | 403 mm | 410 mm |
| Top Tube Length | 525 mm | 535 mm | 549 mm | 559 mm | 571 mm | 586 mm |
| Seat Tube Angle | 74.2 ° | 74.2 ° | 74.2 ° | 74.2 ° | 74.2 ° | 74.2 ° |
| Seat Tube Length | 420 mm | 464 mm | 507 mm | 522 mm | 539 mm | 573 mm |
| Head Tube Angle | 71.2 ° | 71.2 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 95 mm | 122 mm | 138 mm | 154 mm | 173 mm | 198 mm |
| Chainstay Length | 413 mm | 413 mm | 413 mm | 413 mm | 413 mm | 413 mm |
| Wheelbase | 986 mm | 998 mm | 1000 mm | 1011 mm | 1025 mm | 1039 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm |
| Standover Height | 720 mm | 760 mm | 789 mm | 806 mm | 823 mm | 852 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 166 cm | 172 cm | 177 cm | 183 cm | 187 cm |
| Rider Max Height | 168 cm | 174 cm | 180 cm | 186 cm | 192 cm | 196 cm |
Model Overview
Roadmachine 02 ONE belongs to the Bmc Roadmachine model. BMC released 95 bikes variations of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
BMC Roadmachine 03 THREE 2018 is the most economical model, with a starting price of 1799$. BMC Roadmachine 01 ONE 2018 on the other hand costs 11999$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Endurance bikes average price
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When BMC released this model in 2018, its price was 4999$. Doing a quick comparison, we notice that Roadmachine 02 ONE price is 113.09% higher than the average cost of an Endurance bike.
Overview of components
Fork material
Roadmachine 02 ONE has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
As for the wheels, BMC Roadmachine 02 ONE 2018, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Roadmachine 02 ONE has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
BMC Roadmachine 02 ONE bike has 6 sizes, in the range of 152 cm – 196 cm (4.99 ft – 6.43 ft). In short, you can easily find one that suits you.
