Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
51cm
165cm - 174cm
54cm
172cm - 180cm
56cm
178cm - 186cm
58cm
184cm - 192cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Roadmachine Premium Carbon with Tuned Compliance Concept Endurance, Internal Cable Routing, PF86 Bottom Bracket, Flat Mount Disc, 12x142mm Thru-Axle
Suspension Fork
Roadmachine Premium Carbon with Tuned Compliance Concept Endurance, Internal Cable Routing, Flat Mount Disc, 12x100mm Thru-Axle
Drivetrain
Rear Derailleur
SHIMANO Ultegra Di2 RD-R8150 12spd
Shift Levers
SHIMANO Ultegra Di2 ST-R8170 12spd
Cassette
SHIMANO Ultegra CS-R8100 12spd 11-34T
Crank
SHIMANO Ultegra FC-R8100 12spd 50-34T
Bottom Bracket
BB86/BB92, press-fit
Chain
SHIMANO Ultegra CN-M8100 12spd
Wheels
Front Hub
XRD-522
Rear Hub
XRD-522
Rims
XRD-522 - Tubeless Ready - 25mm
Tires
VITTORIA RUBINO - 28mm
Brakes
Brakes
SHIMANO Ultegra BR-R8170 | SHIMANO RT-MT800 160 / 140mm
Cockpit
Stem
BMC RSM01
Handlebar
BMC RAB 03 - Ergo Top Shape - Compact Bend
Seat
Saddle
Fizik Taiga
Seatpost
Roadmachine Premium Carbon D-Shaped Seatpost, 15mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.41 mm | 1.45 mm | 1.5 mm | 1.54 mm | 1.61 mm |
| Bottom Bracket Height | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm |
| Front Center | 583 mm | 599 mm | 597 mm | 609 mm | 621 mm | 635 mm |
| Rake | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm |
| Stack | 519 mm | 544 mm | 565 mm | 589 mm | 613 mm | 647 mm |
| Reach | 377 mm | 385 mm | 389 mm | 393 mm | 397 mm | 401 mm |
| Top Tube Length | 525 mm | 535 mm | 549 mm | 559 mm | 571 mm | 586 mm |
| Seat Tube Angle | 74.2 ° | 74.2 ° | 74.2 ° | 74.2 ° | 74.2 ° | 74.2 ° |
| Seat Tube Length | 420 mm | 457 mm | 500 mm | 522 mm | 539 mm | 573 mm |
| Head Tube Angle | 71.2 ° | 71.2 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 112 mm | 139 mm | 156 mm | 181 mm | 206 mm | 242 mm |
| Chainstay Length | 413 mm | 413 mm | 413 mm | 413 mm | 413 mm | 413 mm |
| Wheelbase | 985 mm | 1002 mm | 1000 mm | 1011 mm | 1023 mm | 1038 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm |
| Standover Height | 722 mm | 753 mm | 785 mm | 808 mm | 828 mm | 862 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 167 cm | 174 cm | 180 cm | 186 cm | 192 cm | cm |
Model Overview
Roadmachine THREE is part of the Bmc Roadmachine model. BMC released 95 bikes variations of this model so far. Take a sneak peek at all Bmc Roadmachine bikes models from 2023, by clicking here.
Model range prices
BMC Roadmachine AL X TWO 2023 is the most affordable bike of this model and has a price of 2499$. On the other hand, BMC Roadmachine 01 ONE 2023, is the most expensive and costs 12999$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Endurance bikes average price
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2023 and its price was 5699$. Comparing the average cost of an Endurance bike to this one, you will see that Roadmachine THREE price is 142.92% higher.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Roadmachine THREE components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the Roadmachine THREE bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Roadmachine THREE has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
