Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Rival -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 172cm
MD
170cm - 182cm
LG
180cm - 192cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ROADMACHINE X Premium Aluminium with Tuned Compliance Concept Gravel, Gravel+ Geometry, Internal Cable Routing, Fender and Rack Mounts, PF86 Bottom Bracket, Flat Mount Disc, 12x142mm Thru-Axle
Suspension Fork
ROADMACHINE X Carbon with Tuned Compliance Concept Gravel, Internal Brake & Hub Dynamo Cable Routing, Fender Mounts, Cargo Mounts, Flat Mount Disc, 12x100mm Thru-Axle, Side Mounts
Drivetrain
Rear Derailleur
SRAM RIVAL
Shift Levers
SRAM RIVAL
Cassette
SRAM PG 1130 11-42T
Crank
SRAM RIVAL 1 40T
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM RIVAL 11 Speed
Wheels
Front Hub
XRD-522
Rear Hub
XRD-522
Rims
XRD-522 - Tubeless Ready - 25 mm
Tires
WTB Expanse - 32mm
Brakes
Brakes
SRAM RIVAL HRD - Centerline Rotors (160/160)
Cockpit
Stem
BMC RSM01
Handlebar
BMC RAB 03 - Ergo Top Shape - Compact Bend
Seat
Saddle
Selle Royal
Seatpost
BMC RSP03
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.38 mm | 1.42 mm | 1.46 mm | 1.49 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 608 mm | 626 mm | 647 mm | 668 mm | 689 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 78 mm | 78 mm | 78 mm | 78 mm | 78 mm |
| Stack | 521 mm | 546 mm | 576 mm | 606 mm | 636 mm |
| Reach | 386 mm | 396 mm | 406 mm | 416 mm | 426 mm |
| Top Tube Length | 536 mm | 554 mm | 572 mm | 591 mm | 610 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 430 mm | 445 mm | 475 mm | 505 mm | 540 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 92 mm | 118 mm | 150 mm | 182 mm | 214 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1024 mm | 1043 mm | 1064 mm | 1085 mm | 1106 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 716 mm | 734 mm | 764 mm | 793 mm | 826 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 165 cm | 172 cm | 182 cm | 192 cm | cm |
Model Overview
Roadmachine X AL ONE belongs to the Bmc Roadmachine model. BMC launched 95 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
BMC Roadmachine AL X TWO 2023 is the most affordable bike of this model and has a price of 2499$. On the other hand, BMC Roadmachine 01 ONE 2023, is the most expensive and costs 12999$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Endurance bikes average price
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, even if your budget is less than the average, you might still be able to get a top-quality Endurance bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, BMC Roadmachine X AL ONE price was 2999$. In conclusion, this bike price is 27.83% higher than the price of the average Endurance bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Roadmachine X AL ONE components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the Roadmachine X AL ONE model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
