Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 130mm -
Fork Fox Factory Float 34
-
Groupset XTR, Race Face -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
01 Premium Carbon (F&R), Internal cable management
Suspension Fork
Fox Float 34, Factory, FIT4, 3-Pos, Kashima (130mm)
Rear Shock
Fox Float DPS, Factory, Evol, 3-Pos, Kashima (130mm)
Drivetrain
Rear Derailleur
Shimano XTR, Shadow Plus
Front Derailleur
N/A
Shift Levers
Shimano XT
Cassette
Shimano XT, 11-42T
Crank
RaceFace Next Carbon DM, 28T
Chain
KMC X-11-1 EPT
Wheels
Front Hub
DT Swiss XM 1501 Spline ONE, Centerlock
Rear Hub
DT Swiss XM 1501 Spline ONE, Centerlock
Rims
DT Swiss XM 1501 Spline ONE 30
Tires
Onza: Ibex FRC 120 (F) / Canis FRC 60 (R), 2.25
Brakes
Brakes
Shimano XT (180/180mm)
Cockpit
Stem
BMC MSM 02
Handlebar
BMC MFB 01 Carbon, 750mm
Seat
Saddle
WTB Volt Team Ti
Seatpost
RockShox Reverb Stealth
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.44 mm | 1.39 mm | 1.34 mm | 1.29 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm | 339 mm |
| Front Center | 672 mm | 694 mm | 716 mm | 738 mm | 760 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 91 mm | 91 mm | 91 mm | 91 mm | 91 mm |
| Stack | 605 mm | 609 mm | 614 mm | 619 mm | 623 mm |
| Reach | 402 mm | 422 mm | 442 mm | 462 mm | 482 mm |
| Top Tube Length | 573 mm | 595 mm | 616 mm | 637 mm | 659 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 390 mm | 420 mm | 460 mm | 500 mm | 530 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 90 mm | 95 mm | 100 mm | 105 mm | 110 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1112 mm | 1134 mm | 1156 mm | 1178 mm | 1199 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 747 mm | 752 mm | 765 mm | 773 mm | 788 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
speedfox 01 completes the Bmc Speedfox model. 28 bikes variations carry this model name so far. Take a sneak peek at all Bmc Speedfox bikes models from 2017, by clicking here.
Model range prices
BMC speedfox 03 2017 is the cheapest bike model and costs 2999$. BMC speedfox 01 2017 is the most expensive one and costs 6499$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When BMC released this model in 2017, its price was 6499$. Doing a quick comparison, we notice that speedfox 01 price is 135.3% more expensive than the average cost of a Trail bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
BMC speedfox 01 2017 bike is equipped with the Fox Factory Float 34 fork, and has 130mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
BMC speedfox 01 bike has the Fox Float DPS model installed, and has a travel of 130mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When leaving the production line, the speedfox 01 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The speedfox 01 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
speedfox 01 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The BMC model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
