Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 29" -
Suspension Full
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
01 Premium Carbon (F&R), Internal cable management
Suspension Fork
-
Rear Shock
Fox Float DPS, Performance Elite, Evol, Remote (120/130mm)***
Drivetrain
Rear Derailleur
-
Front Derailleur
-
Shift Levers
-
Cassette
-
Crank
-
Chain
-
Wheels
Front Hub
-
Rear Hub
-
Rims
-
Tires
-
Brakes
Brakes
-
Cockpit
Stem
-
Handlebar
-
Seat
Saddle
-
Seatpost
BMC Trailsync, 120mm*
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.43 mm | 1.37 mm | 1.38 mm | 1.37 mm |
| Bottom Bracket Height | 352 mm | 337 mm | 352 mm | 337 mm | 337 mm |
| Front Center | 685 mm | 704 mm | 712 mm | 728 mm | 748 mm |
| Rake | 46 mm | 51 mm | 46 mm | 51 mm | 51 mm |
| Trail | 98 mm | 90 mm | 98 mm | 90 mm | 90 mm |
| Stack | 577 mm | 603 mm | 588 mm | 613 mm | 628 mm |
| Reach | 406 mm | 423 mm | 429 mm | 443 mm | 458 mm |
| Top Tube Length | 580 mm | 604 mm | 606 mm | 627 mm | 646 mm |
| Seat Tube Angle | 73.25 ° | 73.25 ° | 73.25 ° | 73.25 ° | 73.25 ° |
| Seat Tube Length | 410 mm | 440 mm | 430 mm | 480 mm | 510 mm |
| Head Tube Angle | 67.5 ° | 68.25 ° | 67.5 ° | 68.25 ° | 68.25 ° |
| Head Tube Length | 110 mm | 105 mm | 120 mm | 115 mm | 135 mm |
| Chainstay Length | 423 mm | 438 mm | 423 mm | 438 mm | 438 mm |
| Wheelbase | 1104 mm | 1138 mm | 1131 mm | 1162 mm | 1182 mm |
| Bottom Bracket Drop | 22 mm | 37 mm | 22 mm | 37 mm | 37 mm |
| Standover Height | 688 mm | 727 mm | 715 mm | 745 mm | 766 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 180 cm | 189 cm | 199 cm |
About this model
Speedfox 01 FRS is part of the Bmc Speedfox model. BMC released 28 frames variations of this model so far. Take a sneak peek at all Bmc Speedfox frames models from 2018, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail frames
According to our math, the average price for a trustworthy Trail frame is 1736$. However, this doesn’t mean that if you spend less money on a Trail frame, you couldn’t get a decent one. In short, before purchasing your ideal frame do some research about its components, and also check for reviews online.
At the moment of the release date, BMC Speedfox 01 FRS price was 4299$. Comparing the average cost of a Trail frame to this one, you will see that Speedfox 01 FRS price is 147.64% more expensive.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
The BMC model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
