Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Pike RC
-
Groupset GX Eagle, Truvativ Stylo -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
M29
158cm - 173cm
L29
171cm - 182cm
XL29
180cm - 189cm
S29
187cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
02 Carbon (F), Al-13 Triple-butted aluminum (R)
Suspension Fork
RockShox Pike RC (130mm), 15x110mm thru-axle
Rear Shock
Fox Float DPS, Performance Elite, Evol, Remote (120mm)
Drivetrain
Rear Derailleur
SRAM GX Eagle
Front Derailleur
-
Shift Levers
SRAM GX Eagle
Cassette
SRAM XG 1275 10-50T
Crank
Truvativ Stylo 6K, 30T
Bottom Bracket
PF92
Chain
SRAM GX Eagle Black
Chain Guide
None
Pedals
None
Wheels
Front Hub
DT Swiss M1700 Spline
Rear Hub
DT Swiss M1700 Spline
Rims
DT Swiss M700 Spline 30 **
Spokes
DT Swiss
Tires
Maxxis Forekaster EXO, 29x2.35
Brakes
Brakes
Shimano XT (180/180mm)
Brake Levers
Shimano XT
Cockpit
Stem
BMC AMSM 02
Handlebar
BMC MRB 02, 760mm
Seat
Saddle
WTB Silverado Race
Seatpost
BMC Trailsync, 100mm *
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | M29 | L29 | XL29 | S29 |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.42 mm | 1.38 mm | 1.36 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm | 337 mm |
| Front Center | 677 mm | 704 mm | 728 mm | 748 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 90 mm | 90 mm | 90 mm | 90 mm |
| Stack | 603 mm | 613 mm | 623 mm | 638 mm |
| Reach | 411 mm | 433 mm | 453 mm | 468 mm |
| Top Tube Length | 590 mm | 614 mm | 637 mm | 656 mm |
| Seat Tube Angle | 73.75 ° | 73.75 ° | 73.75 ° | 73.75 ° |
| Seat Tube Length | 420 mm | 440 mm | 480 mm | 510 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 135 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1126 mm | 1148 mm | 1172 mm | 1192 mm |
| Bottom Bracket Drop | 37 mm | 37 mm | 37 mm | 37 mm |
| Standover Height | 716 mm | 737 mm | 755 mm | 776 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 171 cm | 180 cm | 187 cm |
| Rider Max Height | 173 cm | 182 cm | 189 cm | 199 cm |
About this model
SPEEDFOX 02 ONE is part of the Bmc Speedfox model. There are 28 bikes that carry this model name. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
BMC SPEEDFOX 03 TWO 2019 is the most economical model, with a starting price of 2199$. BMC SPEEDFOX 01 ONE 2019 on the other hand costs 6499$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5199$. Comparing the average cost of a Trail bike to this one, you will see that SPEEDFOX 02 ONE price is 88.23% more expensive.
SPEEDFOX 02 ONE components
Fork
This bike has the RockShox Pike RC fork installed. The fork’s travel is 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
BMC SPEEDFOX 02 ONE bike has the Fox Float DPS model installed, and has a travel of 120mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
When it comes to wheels, the SPEEDFOX 02 ONE bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The SPEEDFOX 02 ONE has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
BMC SPEEDFOX 02 ONE bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
BMC SPEEDFOX 02 ONE comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
