Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork Fox Performance Float 32
-
Groupset XT, SLX -
Suspension Hardtail -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
02 Carbon, Tuned Compliance Concept, DTi
Suspension Fork
Fox Float 32 SC, Performance Series, Grip, Remote (100mm)
Rear Shock
-
Drivetrain
Rear Derailleur
Shimano XT, Shadow Plus
Front Derailleur
New Shimano SLX
Shift Levers
New Shimano SLX
Cassette
New Shimano SLX, 11-40T
Crank
Shimano XT, 36-26T
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano CN-HG601
Wheels
Front Hub
DT Swiss X1700 Spline
Rear Hub
DT Swiss X1700 Spline
Rims
DT Swiss X1700 Spline
Tires
Continental: X-King (F) / RaceKing (R), Performance Silver, 2.2
Brakes
Brakes
New Shimano SLX (160/160mm)
Cockpit
Stem
BMC MSM 02
Handlebar
BMC MFB 02, 720mm
Seat
Saddle
Fizik Tundra M7 Versus
Seatpost
BMC MSP 02
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.589 mm | 1.516 mm | 1.451 mm | 1.421 mm | 1.393 mm |
| Bottom Bracket Height | 313 mm | 313 mm | 313 mm | 313 mm | 313 mm |
| Front Center | 625 mm | 659 mm | 685 mm | 706 mm | 725 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Stack | 599 mm | 608 mm | 618 mm | 628 mm | 638 mm |
| Reach | 377 mm | 401 mm | 426 mm | 442 mm | 458 mm |
| Top Tube Length | 550 mm | 584 mm | 610 mm | 630 mm | 649 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 400 mm | 445 mm | 485 mm | 525 mm | 545 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1046 mm | 1081 mm | 1107 mm | 1128 mm | 1146 mm |
| Bottom Bracket Drop | 61 mm | 61 mm | 61 mm | 61 mm | 61 mm |
| Standover Height | 687 mm | 773 mm | 803 mm | 828 mm | 838 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
teamelite 02 belongs to the Bmc Teamelite model. There are 27 bikes that carry this model name. You can get a glimpse at all models from 2017, by clicking on this link.
Model range prices
BMC teamelite 03 2017 is the cheapest bike model and costs 1699$. BMC teamelite 01 2017 is the most expensive one and costs 10599$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2017 for 3799$. In conclusion, this bike price is 99.42% higher than the price of the average Crosscountry bike.
teamelite 02 components
Fork
The fork installed on this bike is the Fox Performance Float 32 model. The travel on this model is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When leaving the production line, the teamelite 02 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. BMC teamelite 02 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
teamelite 02 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
