Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED AXS -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
51cm
165cm - 174cm
54cm
172cm - 180cm
56cm
178cm - 186cm
58cm
184cm - 192cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Teammachine R 01 Premium Carbon with Aerocore Design | ICS Technology, Stealth Cable Routing | Integrated Aerocore Bottle Cages | Stealth Dropout Design | PF86 Bottom Bracket | Flat Mount Disc | 12x142mm Thru-Axle
Suspension Fork
Teammachine R 01 Premium Carbon | ICS Technology | Stealth Cable Routing | Stealth Dropout Design | Flat Mount Disc | 12x100mm Thru-Axle
Drivetrain
Rear Derailleur
SRAM RED eTap AXS
Front Derailleur
SRAM RED eTap AXS
Shift Levers
SRAM RED eTap AXS
Cassette
SRAM RED XG1290 10-28T
Crank
SRAM RED AXS 48-35T Power Meter
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM RED 12 Speed
Wheels
Front Hub
DT Swiss 180 Straightpull - Ratchet EXP 36 - SINC Ceramic Bearings
Rear Hub
DT Swiss 180 Straightpull - Ratchet EXP 36 - SINC Ceramic Bearings
Rims
DT Swiss ARC 1100 62mm
Tires
Pirelli P-Zero Race SL TLR, 26mm
Brakes
Brakes
Hydraulic Disc
Cockpit
Handlebar
ICS Carbon Aero | One-Piece Full Carbon Cockpit
Seat
Saddle
Fizik Argo Vento R1 (140mm)
Seatpost
Teammachine R 01 Premium Carbon Seatpost | 10mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.397 mm | 1.416 mm | 1.433 mm | 1.448 mm | 1.487 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 568 mm | 586 mm | 589 mm | 599 mm | 614 mm | 630 mm |
| Rake | 48 mm | 48 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm |
| Stack | 504 mm | 528 mm | 548 mm | 563 mm | 582 mm | 608 mm |
| Reach | 368 mm | 378 mm | 387 mm | 393 mm | 402 mm | 409 mm |
| Top Tube Length | 522 mm | 532 mm | 552 mm | 562 mm | 582 mm | 598 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 418 mm | 463 mm | 499 mm | 519 mm | 541 mm | 570 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 72.3 ° | 72.3 ° | 72.3 ° | 72.3 ° |
| Head Tube Length | 108 mm | 133 mm | 149 mm | 165 mm | 185 mm | 211 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 968 mm | 986 mm | 989 mm | 999 mm | 1015 mm | 1030 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 167 cm | 174 cm | 180 cm | 186 cm | 192 cm | cm |
About this model
Teammachine R 01 LTD belongs to the Bmc Teammachine model. There are 163 bikes that carry this model name. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
The most economical model, the BMC Teammachine R 01 MOD 2024 has a starting price of 6352$. BMC Teammachine R 01 LTD 2024 on the other hand is the most expensive at 15883$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Race bikes average price
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When BMC released this model in 2024, its price was 15883$. In conclusion, this bike price is 374.12% more expensive than the price of the average Race bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Teammachine R 01 LTD components
Fork material
Teammachine R 01 LTD has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
When leaving the production line, the Teammachine R 01 LTD model has 700c carbon wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. BMC Teammachine R 01 LTD is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
