Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
51cm
165cm - 174cm
54cm
172cm - 180cm
56cm
178cm - 186cm
58cm
184cm - 192cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
"Teammachine SLR 01 Premium Carbon with Aerocore Design • ICS Technology, Stealth Cable Routing • Integrated Aerocore Bottle Cages • Stealth Dropout Design • TCC Race Compliance Level • PF86 Bottom Bracket • Integrated Seatpost Clamp • Flat Mount Disc •
Suspension Fork
Teammachine SLR 01 Premium Carbon, • ICS Technology, Stealth Cable Routing, • TCC Race Compliance Level, • Stealth Dropout Design, • Flat Mount Disc, • 12x100mm Thru-Axle, • 48mm Offset (Size 47-51), 43mm Offset (Size 54-61)
Drivetrain
Rear Derailleur
SHIMANO Ultegra Di2
Front Derailleur
SHIMANO Ultegra Di2
Shift Levers
SHIMANO Ultegra Di2
Cassette
SHIMANO Ultegra 11-30T
Crank
SHIMANO Ultegra 52-36T
Bottom Bracket
BB86/BB92, press-fit
Chain
SHIMANO Ultegra
Wheels
Front Hub
CRD-351
Rear Hub
CRD-351
Rims
SHIMANO Ultegra, RT-MT800 Rotors (160/140)
Tires
Vittoria Corsa, 25mm
Brakes
Brakes
SHIMANO Ultegra, RT-MT800 Rotors (160/140)
Cockpit
Stem
BMC ICS2 - Integrated Cockpit Design
Handlebar
BMC RAB 02, Ergo Top Shape, Compact Bend
Seat
Saddle
Fizik Argo Vento R5 (140mm)
Seatpost
Teammachine SLR 01 Premium Carbon D-Shaped Seatpost, • 15mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.4 mm | 1.42 mm | 1.43 mm | 1.45 mm | 1.48 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 568 mm | 586 mm | 589 mm | 599 mm | 614 mm | 630 mm |
| Rake | 48 mm | 48 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm |
| Stack | 512 mm | 536 mm | 556 mm | 571 mm | 590 mm | 614 mm |
| Reach | 373 mm | 383 mm | 392 mm | 398 mm | 407 mm | 415 mm |
| Top Tube Length | 523 mm | 540 mm | 555 mm | 565 mm | 580 mm | 595 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 423 mm | 468 mm | 504 mm | 524 mm | 545 mm | 574 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 72.3 ° | 72.3 ° | 72.3 ° | 72.3 ° |
| Head Tube Length | 110 mm | 130 mm | 145 mm | 165 mm | 184 mm | 210 mm |
| Chainstay Length | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm |
| Wheelbase | 974 mm | 992 mm | 995 mm | 1006 mm | 1021 mm | 1036 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 167 cm | 174 cm | 180 cm | 186 cm | 192 cm | cm |
About this model
Teammachine SLR01 FIVE is part of the Bmc Teammachine model. There are 158 bikes that carry this model name. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
BMC Teammachine ALR TWO 2022 is the cheapest bike model and costs 2299$. BMC Teammachine SLR01, TEAM P2P 2022 is the most expensive one and costs 15641$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Race bikes average price
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, BMC Teammachine SLR01 FIVE price was 6999$. If we compare this with the average Race bike cost we notice that the price is 108.93% more expensive.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Teammachine SLR01 FIVE components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The Teammachine SLR01 FIVE 2022 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. BMC Teammachine SLR01 FIVE has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
