Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
51cm
165cm - 174cm
54cm
172cm - 180cm
56cm
178cm - 186cm
58cm
184cm - 192cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Teammachine SLR 01 Premium Carbon with Aerocore Design, • ICS Technology, • Integrated Aerocore Bottle Cages, • Stealth Dropout Design, • TCC Race Compliance Level, • PF86 Bottom Bracket, • Flat Mount Disc, • 12x142mm Thru-Axle
Suspension Fork
Teammachine SLR 01 Premium Carbon, • ICS Technology, Stealth Cable Routing, • TCC Race Compliance Level, • Stealth Dropout Design, • Flat Mount Disc, • 12x100mm Thru-Axle, • 48mm Offset (Size 47-51), 43mm Offset (Size 54-61)
Drivetrain
Rear Derailleur
SHIMANO Dura Ace Di2
Front Derailleur
SHIMANO Dura Ace Di2
Shift Levers
SHIMANO Dura Ace Di2
Cassette
SHIMANO Dura Ace 11-30T
Crank
SHIMANO Dura Ace 52-36T
Bottom Bracket
BB86/BB92, press-fit
Chain
SHIMANO Dura Ace
Wheels
Front Hub
DT Swiss 180 Straightpull, Ratchet EXP 36, SINC Ceramic Bearings
Rear Hub
DT Swiss 180 Straightpull, Ratchet EXP 36, SINC Ceramic Bearings
Rims
DT Swiss PRC 1100 DISC MON CHASSERAL, 24mm
Tires
Pirelli P ZERO RACE TLR SL
Brakes
Brakes
SHIMANO Dura Ace, RT900 Rotors (160/140)
Cockpit
Stem
ICS Carbon, One-Piece Full Carbon Cockpit
Handlebar
ICS Carbon, One-Piece Full Carbon Cockpit
Seat
Saddle
Fizik Argo Vento 00 140mm
Seatpost
Teammachine SLR 01 Premium Carbon D-Shaped Seatpost, • 15mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.4 mm | 1.42 mm | 1.43 mm | 1.45 mm | 1.48 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 568 mm | 586 mm | 589 mm | 599 mm | 614 mm | 630 mm |
| Rake | 48 mm | 48 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm |
| Stack | 512 mm | 536 mm | 556 mm | 571 mm | 590 mm | 614 mm |
| Reach | 373 mm | 383 mm | 392 mm | 398 mm | 407 mm | 415 mm |
| Top Tube Length | 523 mm | 540 mm | 555 mm | 565 mm | 580 mm | 595 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 423 mm | 468 mm | 504 mm | 524 mm | 545 mm | 574 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 72.3 ° | 72.3 ° | 72.3 ° | 72.3 ° |
| Head Tube Length | 110 mm | 130 mm | 145 mm | 165 mm | 184 mm | 210 mm |
| Chainstay Length | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm |
| Wheelbase | 974 mm | 992 mm | 995 mm | 1006 mm | 1021 mm | 1036 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 167 cm | 174 cm | 180 cm | 186 cm | 192 cm | cm |
Model Overview
Teammachine SLR01 ONE is a Bmc Teammachine model. BMC launched 158 bikes of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
BMC Teammachine ALR TWO 2022 is the cheapest bike model and costs 2299$. BMC Teammachine SLR01, TEAM P2P 2022 is the most expensive one and costs 15641$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Race bikes
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 12999$. Comparing this to the average Race bike price, we see that the price is 288.03% more expensive.
Overview of components
Fork material
Teammachine SLR01 ONE has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The wheels on Teammachine SLR01 ONE are the 700c carbon type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. BMC Teammachine SLR01 ONE has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
