Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ACE Technology, 03 Carbon
Suspension Fork
Teammachine SLR, 03 Carbon
Rear Shock
-
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano Ultegra
Cassette
Shimano 105, 11-32T
Crank
Shimano FC-RS500, 50-34T
Chain
Shimano 105
Wheels
Front Hub
Shimano RS11
Rear Hub
Shimano RS11
Rims
Shimano RS11
Tires
Continental Ultra Sport II SL, 23mm
Brakes
Brakes
Shimano BR-R561
Cockpit
Stem
BMC RSM 03
Handlebar
BMC RDM 03
Seat
Saddle
Selle Royal Seta
Seatpost
BMC RSP 03
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 57cm | 60cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.41 mm | 1.43 mm | 1.46 mm | 1.49 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 571 mm | 575 mm | 586 mm | 600 mm | 620 mm |
| Rake | 41.6 mm | 41.6 mm | 41.6 mm | 42 mm | 41.6 mm |
| Trail | 76 mm | 66 mm | 63 mm | 63 mm | 63 mm |
| Stack | 497 mm | 521 mm | 541 mm | 562 mm | 592 mm |
| Reach | 361 mm | 369 mm | 378 mm | 385 mm | 396 mm |
| Top Tube Length | 511 mm | 526 mm | 541 mm | 555 mm | 574 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 442 mm | 505 mm | 535 mm | 565 mm | 600 mm |
| Head Tube Angle | 70.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 108 mm | 128 mm | 148 mm | 170 mm | 201 mm |
| Chainstay Length | 393 mm | 393 mm | 393 mm | 393 mm | 393 mm |
| Wheelbase | 954 mm | 958 mm | 969 mm | 983 mm | 1003 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 698 mm | 745 mm | 770 mm | 795 mm | 827 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
teammachine SLR03 belongs to the Bmc Teammachine model. 158 bikes variations carry this model name so far. Take a sneak peek at all Bmc Teammachine bikes models from 2017, by clicking here.
Model range prices
BMC teammachine ALR01 2017 is the most affordable bike of this model and has a price of 2099$. On the other hand, BMC teammachine SLR01 DISC 2017, is the most expensive and costs 11999$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Race bikes
If you want an acceptable Race bike you should know that the average price is 3350$. However, this doesn’t mean that if you spend less money on a Race bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, BMC teammachine SLR03 price was 2799$. Comparing this to the average Race bike price, we see that the price is 19.69% smaller.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The wheels on teammachine SLR03 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. BMC teammachine SLR03 has Rim brakes installed. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
