Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTap, RED AXS -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD-Short
172cm - 180cm
MD/LG
178cm - 188cm
LG
186cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Timemachine 01 Disc Premium Carbon with Vmax Aero Design and P2P Positioning SyStem, Internal Di2 Battery Mount, PF86 Bottom Bracket, Rear Storage Box, Aero Caliper Cover, Sliding Dropouts, Flat Mount Disc, 12x142mm Thru-Axle
Suspension Fork
Timemachine 01 Disc Premium Carbon with Vmax Aero Design Hinge Design, Aero Caliper Cover, Flat Mount Disc, 12x100mm Thru-Axle
Drivetrain
Rear Derailleur
SRAM FORCE eTap AXS
Shift Levers
SRAM eTap AXS
Cassette
SRAM FORCE XG-1270 10-28T
Crank
SRAM FORCE AXS 48-35T
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM FORCE 12 Speed
Wheels
Front Hub
DT Swiss ARC 1650 Disc
Rear Hub
DT Swiss ARC 1650 Disc
Rims
DT Swiss ARC 1650 Carbon Disc - 62mm
Tires
Pirelli P ZERO RACE - 26mm
Brakes
Brakes
SRAM S-900 Aero HRD Disc Brake | SRAM Centerline X 160 / 160mm
Cockpit
Stem
BMC Flat Cockpit
Handlebar
BMC Flat Cockpit / Profile T4+ Carbon Extensions
Seat
Saddle
Fizik Mistica Mg
Seatpost
P2P Flat Cockpit, BMC Aero
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD-Short | SM | MD/LG | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.22 mm | 1.23 mm | 1.26 mm |
| Bottom Bracket Height | 268 mm | 278 mm | 268 mm | 268 mm |
| Front Center | 578 mm | 580 mm | 619 mm | 649 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 60 mm | 60 mm | 60 mm | 60 mm |
| Stack | 512 mm | 477 mm | 512 mm | 553 mm |
| Reach | 374 mm | 390 mm | 415 mm | 439 mm |
| Seat Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Seat Tube Length | 550 mm | 495 mm | 550 mm | 592 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Chainstay Length | 397 mm | 397 mm | 397 mm | 397 mm |
| Wheelbase | 965 mm | 969 mm | 1006 mm | 1036 mm |
| Bottom Bracket Drop | 68 mm | 58 mm | 68 mm | 68 mm |
| Standover Height | 794 mm | 752 mm | 794 mm | 835 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 172 cm | cm | 178 cm | 186 cm |
| Rider Max Height | 180 cm | 170 cm | 188 cm | 196 cm |
Model Overview
Timemachine 01 DISC ONE belongs to the Bmc Timemachine model. BMC released 70 bikes variations of this model so far. Take a sneak peek at all Bmc Timemachine bikes models from 2023, by clicking here.
Model range prices
BMC Timemachine ONE 2023 is the cheapest bike model and costs 3299$. BMC Timemachine ROAD 01 ONE 2023 is the most expensive one and costs 13499$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Triathlon bikes average price
If you want an acceptable Triathlon bike you should know that the average price is 4177$. However, you could also get a good Triathlon bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When BMC released this model in 2023, its price was 9999$. If we compare this with the average Triathlon bike cost we notice that the price is 139.38% more expensive.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Timemachine 01 DISC ONE components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The wheels on Timemachine 01 DISC ONE are the 700c carbon type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
