Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
51cm
165cm - 174cm
54cm
172cm - 180cm
56cm
178cm - 186cm
58cm
184cm - 192cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Timemachine Road 01 Premium Carbon with Aero Module Tuned Compliance Concept Speed, ICS Aero Technology Stealth Cable Routing, PF86 Bottom Bracket, Flat Mount Disc, 12x142mm Thru-Axle
Suspension Fork
Timemachine Road 01 Premium Carbon with Integrated Aero Cover Tuned Compliance Concept Speed, ICS Technology Stealth Cable Routing, Flat Mount Disc, 12x100mm Thru-Axle
Drivetrain
Rear Derailleur
SHIMANO Ultegra Di2 RD-R8150 12spd
Shift Levers
SHIMANO Ultegra Di2 ST-R8170 12spd
Cassette
SHIMANO Ultegra CS-R8100 12spd 11-30T
Crank
SHIMANO Ultegra FC-R8100 12spd 52-36T
Bottom Bracket
BB86/BB92, press-fit
Chain
SHIMANO Ultegra CN-M8100 12spd
Wheels
Front Hub
CRD-501 SL
Rear Hub
CRD-501 SL
Rims
CRD-501 SL Carbon - Tubeless Ready - 50mm
Tires
Vittoria Corsa - 25mm
Brakes
Brakes
SHIMANO Ultegra BR-R8170 | SHIMANO RT-MT800 Rotors 160 / 140mm
Cockpit
Stem
ICS Carbon Aero - One-Piece Full Carbon Cockpit
Handlebar
ICS Carbon Aero - One-Piece Full Carbon Cockpit
Seat
Saddle
Fizik Argo Vento R5 (140mm)
Seatpost
Timemachine Road 01 Premium Carbon Aero Seatpost, 0. 15. 30mm Adjustable Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.33 mm | 1.37 mm | 1.39 mm | 1.41 mm | 1.42 mm | 1.45 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 577 mm | 592 mm | 594 mm | 604 mm | 620 mm | 636 mm |
| Rake | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm |
| Stack | 491 mm | 515 mm | 535 mm | 550 mm | 569 mm | 593 mm |
| Reach | 368 mm | 376 mm | 385 mm | 390 mm | 400 mm | 408 mm |
| Top Tube Length | 515 mm | 530 mm | 545 mm | 555 mm | 570 mm | 585 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 480 mm | 518 mm | 548 mm | 568 mm | 588 mm | 611 mm |
| Head Tube Angle | 71.2 ° | 71.2 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 88 mm | 113 mm | 135 mm | 150 mm | 170 mm | 196 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 970 mm | 986 mm | 989 mm | 999 mm | 1015 mm | 1031 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 738 mm | 769 mm | 794 mm | 811 mm | 829 mm | 853 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 167 cm | 174 cm | 180 cm | 186 cm | 192 cm | cm |
Model Overview
Timemachine ROAD 01 TWO is part of the Bmc Timemachine model. There are 70 bikes that carry this model name. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
BMC Timemachine ONE 2023 is the most affordable bike of this model and has a price of 3299$. On the other hand, BMC Timemachine ROAD 01 ONE 2023, is the most expensive and costs 13499$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Aero bikes
If you want an acceptable Aero bike you should know that the average price is 4211$. However, even if your budget is less than the average, you might still be able to get a top-quality Aero bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When BMC released this model in 2023, its price was 9299$. In conclusion, this bike price is 120.83% more expensive than the price of the average Aero bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Timemachine ROAD 01 TWO components
Fork material
Timemachine ROAD 01 TWO has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
As for the wheels, BMC Timemachine ROAD 01 TWO 2023, has a 700c carbon model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Timemachine ROAD 01 TWO has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
