Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aerodynamic 01 Premium Carbon, Vmax Aero Technology
Suspension Fork
Aero 02 Carbon, subA Aero Technology
Rear Shock
-
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano Ultegra
Cassette
Shimano Ultegra, 11-28T
Crank
Shimano Ultegra, 52-36T
Chain
Shimano Ultegra
Wheels
Front Hub
Shimano RS330
Rear Hub
Shimano RS330
Rims
Shimano RS330
Tires
Continental Ultra Sport II SL, 23mm
Brakes
Brakes
Vmax Aero Integrated Design (R) / Shimano Ultegra (F)
Cockpit
Stem
BMC RSM 01
Handlebar
BMC RAB 02
Seat
Saddle
Fizik Arione R7 Manganese
Seatpost
Vmax Aero Post, 01 Premium Carbon, P2P and SubA Technology
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.38 mm | 1.41 mm | 1.42 mm | 1.42 mm | 1.47 mm |
| Bottom Bracket Height | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm | 267 mm |
| Front Center | 573 mm | 574 mm | 584 mm | 595 mm | 609 mm | 627 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 75 mm | 66 mm | 63 mm | 63 mm | 63 mm | 63 mm |
| Stack | 510 mm | 530 mm | 550 mm | 565 mm | 565 mm | 610 mm |
| Reach | 375 mm | 383 mm | 391 mm | 397 mm | 397 mm | 415 mm |
| Top Tube Length | 520 mm | 534 mm | 547 mm | 558 mm | 571 mm | 588 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 524 mm | 546 mm | 567 mm | 583 mm | 603 mm | 629 mm |
| Head Tube Angle | 70.5 ° | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 109 mm | 125 mm | 144 mm | 160 mm | 181 mm | 207 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 973 mm | 974 mm | 984 mm | 995 mm | 1009 mm | 1027 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 765 mm | 785 mm | 805 mm | 820 mm | 840 mm | 865 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
timemachine TMR02 is part of the Bmc Timemachine model. There are 70 bikes that carry this model name. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
BMC timemachine TMR02 2017 is the cheapest bike model and costs 3499$. BMC timemachine 01 2017 is the most expensive one and costs 12999$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Triathlon bikes average price
If you want to purchase a solid Triathlon bike, it is important to know that the average cost is 4177$. However, even though the average price of a Triathlon bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When BMC released this model in 2017, its price was 3499$. Comparing this to the average Triathlon bike price, we see that the price is 19.38% smaller.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When leaving the production line, the timemachine TMR02 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. BMC timemachine TMR02 has Rim brakes installed. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
