Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Suspension Rigid -
Drivetrain Single Speed
Sizing
Recommended size guide.
MD
170cm - 185cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Al-13 Premium Triple-butted, Hydroformed Aluminium
Suspension Fork
Aero 02 Carbon, subA Aero Technology
Drivetrain
Cassette
Miche Pista Steel, 15T
Crank
Miche Advanced Pista, 48T
Chain
Miche Pista, 1/8"
Wheels
Front Hub
DT Swiss Track 100/120
Rear Hub
DT Swiss Track 100/120
Rims
DT Swiss Track Aero
Tires
Continental Grand Sport Race SL, 23mm
Cockpit
Stem
BMC RSM 03
Handlebar
BMC RAB 03, ergo top shape, compact bend
Seat
Saddle
VL-1205
Seatpost
Trackmachine 02 Airfoil post, carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.24 mm | 1.31 mm | 1.36 mm |
| Bottom Bracket Height | 286 mm | 278 mm | 278 mm |
| Front Center | 577 mm | 592 mm | 616 mm |
| Rake | 43 mm | 43 mm | 43 mm |
| Trail | 58 mm | 58 mm | 58 mm |
| Stack | 491 mm | 526 mm | 564 mm |
| Reach | 396 mm | 403 mm | 414 mm |
| Top Tube Length | 541 mm | 559 mm | 581 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 520 mm | 550 mm | 585 mm |
| Head Tube Angle | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 110 mm | 138 mm | 178 mm |
| Chainstay Length | 391 mm | 391 mm | 391 mm |
| Wheelbase | 957 mm | 976 mm | 1000 mm |
| Bottom Bracket Drop | 50 mm | 58 mm | 58 mm |
| Wheels | 700 | 700 | 700 |
| Rider Max Height | 173 cm | 185 cm | cm |
Model Overview
TRACKMACHINE 02 completes the Bmc Trackmachine model. There are 14 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
BMC TRACKMACHINE 02 2019 is the cheapest bike model and costs 1899$. BMC Trackmachine 02 Miche 2019 is the most expensive one and costs 1899$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Track bikes
According to our calculations, the average cost of a Track bike that is reliable is 1503$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Track bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When BMC released this model in 2019, its price was 1899$. Doing a quick comparison, we notice that TRACKMACHINE 02 price is 26.35% higher than the average cost of a Track bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
As for the wheels, BMC TRACKMACHINE 02 2019, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
