Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Suspension Rigid -
Drivetrain Single Speed
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Al-13 Premium Triple-butted, Hydroformed Aluminum
Suspension Fork
Aero 02 Carbon, subA Aero Technology
Rear Shock
-
Drivetrain
Rear Derailleur
-
Front Derailleur
-
Shift Levers
-
Cassette
Miche Pista Steel, 15T
Crank
Miche Advanced Pista, 48T
Chain
Miche Pista, 1/8"
Wheels
Front Hub
DT Swiss Track 100/120
Rear Hub
DT Swiss Track 100/120
Rims
DT Swiss Track Aero
Tires
Continental Grand Sport Race SL, 23mm
Brakes
Brakes
-
Cockpit
Stem
BMC RSM 03
Handlebar
BMC RAB 03
Seat
Saddle
Velo VL-1205
Seatpost
Trackmachine 02 Airfoil post, carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.24 mm | 1.31 mm | 1.36 mm |
| Bottom Bracket Height | 286 mm | 278 mm | 278 mm |
| Front Center | 577 mm | 592 mm | 616 mm |
| Rake | 43 mm | 43 mm | 43 mm |
| Trail | 58 mm | 58 mm | 58 mm |
| Stack | 491 mm | 526 mm | 564 mm |
| Reach | 396 mm | 403 mm | 414 mm |
| Top Tube Length | 541 mm | 559 mm | 581 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 520 mm | 550 mm | 585 mm |
| Head Tube Angle | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 110 mm | 138 mm | 178 mm |
| Chainstay Length | 391 mm | 391 mm | 391 mm |
| Wheelbase | 957 mm | 976 mm | 1000 mm |
| Bottom Bracket Drop | 50 mm | 58 mm | 58 mm |
| Standover Height | 750 mm | 781 mm | 808 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
trackmachine TR02 is part of the Bmc Trackmachine model. BMC launched 14 bikes of this model so far. Take a sneak peek at all Bmc Trackmachine bikes models from 2017, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Track bikes
According to our calculations, the average cost of a Track bike that is reliable is 1503$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Track bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1899$. Doing a quick comparison, we notice that trackmachine TR02 price is 26.35% more expensive than the average cost of a Track bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When it comes to wheels, the trackmachine TR02 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
