Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox
-
Groupset GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
01 Premium Carbon (F), Al-13 Triple-butted aluminum (R)
Suspension Fork
Rockshox Lyric RC Solor Air (160mm)
Rear Shock
Cane Creek DB Inline (150mm)
Drivetrain
Rear Derailleur
SRAM GX Eagle
Front Derailleur
-
Shift Levers
SRAM GX Eagle Trigger
Cassette
SRAM XG-1275, 10-50T
Crank
SRAM GX Eagle, 32T Black
Bottom Bracket
SRAM PF92
Chain
SRAM GX Eagle
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
DT Swiss M1700 Spline
Rear Hub
DT Swiss M1700 Spline
Rims
DT Swiss M1700 Spline 30**
Spokes
DT Swiss
Tires
Maxxis Minion DHF EXO/3C, 2.35 (F) / Maxxis Minion DHR EXO/3C, 2.3 (R)
Brakes
Brakes
Shimano XT (203/203mm)*
Brake Levers
Shimano XT
Cockpit
Stem
BMC AMSM 02, 45mm
Handlebar
BMC MRB 02, 780mm
Seat
Saddle
WTB Volt Race
Seatpost
RaceFace Turbine Dropper 150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.488 mm | 1.414 mm | 1.346 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm |
| Front Center | 712 mm | 739 mm | 766 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 101 mm | 101 mm | 101 mm |
| Stack | 610 mm | 615 mm | 619 mm |
| Reach | 410 mm | 435 mm | 460 mm |
| Top Tube Length | 585 mm | 611 mm | 638 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 95 mm | 100 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1045 mm | 1173 mm | 1200 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm |
| Standover Height | 725 mm | 735 mm | 745 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Trailfox 02 ONE belongs to the Bmc Trailfox model. BMC launched 7 bikes of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
BMC Trailfox 03 TWO 2018 is the cheapest bike model and costs 3499$. BMC Trailfox 02 ONE 2018 is the most expensive one and costs 5299$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Enduro bikes
According to our calculations, the average cost of an Enduro bike that is reliable is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When BMC released this model in 2018, its price was 5299$. Comparing this to the average Enduro bike price, we see that the price is 47.24% higher.
Trailfox 02 ONE components
Fork
This bike has the RockShox fork installed. The fork’s travel is 160mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
BMC Trailfox 02 ONE bike has the Cane Creek DB Inline (150mm) model installed, and has a travel of 150mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
As for the wheels, BMC Trailfox 02 ONE 2018, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. BMC Trailfox 02 ONE is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Trailfox 02 ONE comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The BMC model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
