Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox Pike RC
-
Groupset X1, GX -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Al-13 Premium Triple-butted aluminum (F&R)
Suspension Fork
RockShox Pike RC Solo Air (160mm)
Rear Shock
Cane Creek DB Inline (150mm)
Drivetrain
Rear Derailleur
SRAM X1 X-HORIZON
Front Derailleur
-
Shift Levers
SRAM GX-11
Cassette
SRAM PG1150, 10-42T
Crank
RaceFace Aeffect SL DM, 30T
Chain
KMC X-11-1 EPT
Wheels
Front Hub
SRAM MTH-716
Rear Hub
SRAM MTH-716
Rims
DT Swiss E512
Tires
Onza: Ibex AM FR 120 (F) / AM 60 (R), 2.4
Brakes
Brakes
Shimano SLX (203/203mm)
Cockpit
Stem
BMC AMSM 02, 45mm
Handlebar
BMC MFB 02, 780mm
Seat
Saddle
Fizik Nisene XS
Seatpost
HDK Dropper Stealth, 125mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.488 mm | 1.414 mm | 1.346 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm |
| Front Center | 712 mm | 739 mm | 766 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 101 mm | 101 mm | 101 mm |
| Stack | 610 mm | 615 mm | 619 mm |
| Reach | 410 mm | 435 mm | 460 mm |
| Top Tube Length | 585 mm | 611 mm | 638 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 95 mm | 100 mm |
| Chainstay Length | 438 mm | 435 mm | 435 mm |
| Wheelbase | 1145 mm | 1173 mm | 1200 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm |
| Standover Height | 725 mm | 735 mm | 745 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
trailfox 03 belongs to the Bmc Trailfox model. BMC launched 7 bikes of this model so far. Take a sneak peek at all Bmc Trailfox bikes models from 2017, by clicking here.
Model range prices
The most economical model, the BMC trailfox 03 2017 has a starting price of 3999$. BMC trailfox 02 2017 on the other hand is the most expensive at 5999$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Enduro bikes
According to our calculations, the average cost of an Enduro bike that is reliable is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2017 for 3999$. Comparing this to the average Enduro bike price, we see that the price is 11.11% higher.
Overview of components
Fork
The RockShox Pike RC is included from the factory. It has a travel distance of 160mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
As for the rear shock, this bike has the Cane Creek DB Inline (150mm) model, with a travel of 150mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
As for the wheels, BMC trailfox 03 2017, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The trailfox 03 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
BMC trailfox 03 includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
