Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Travel Rear 135mm -
Fork Fox Performance Elite Float 36
-
Groupset X01 Eagle AXS, GX Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bold Linkin 135 / Carbon HMX, Integrated Suspension Technology / IST VP, Vario Tech, Head angle and BB height / Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
Suspension Fork
FOX 36 Float Performance Elite Grip 2 Air, HSC - LSC - HSR- LSR adjustable / Kabolt 15x110mm axle, 44mm offset / tapered steerer, 140mm travel
Rear Shock
FOX NUDE 5T EVOL Trunnion, Custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend, Custom large Air volume / DPS / Reb. Adj. Travel 135-90-Lockout / T185X55mm
Drivetrain
Rear Derailleur
SRAM X01 Eagle AXS / 12 Speed, Wireless Electronic Shift System
Shift Levers
SRAM GX Eagle AXS Rocker Controller
Cassette
SRAM GX XG1275 / 10-52 T
Crank
SRAM GX Eagle DUB, 55mm CL / 32T
Bottom Bracket
SRAM DUB PF 92 MTB Wide / shell 41x92mm
Chain
SRAM CN GX Eagle
Wheels
Rims
DT Swiss XM 1850 Spline 6 Bolt, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready rim 28H / XD Driver, Syncros Axle w/Removable Lever with Tool
Tires
Front: Maxxis Dissector / 2.4" / 60TPI Foldable, Tubeless Ready / EXO, Rear: Maxxis Dissector / 2.4" / 60TPI Foldable, Tubeless Ready / EXO
Brakes
Brakes
Shimano XT M8120 4 Piston Disc
Cockpit
Handlebar
Syncros Hixon iC Carbon, Size S & M 15mm rise / Size L & XL 25mm rise, Back sweep 8° / 780mm, Syncros Pro lock-on grips
Headset
Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
Seat
Saddle
Syncros Tofino 1.5 Regular, Titanium rails
Seatpost
Syncros Duncan Dropper Post 1.5 34.9mm, Size S 150mm / Size M 170mm / Size L & XL 200mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.44 mm | 1.33 mm | 1.35 mm | 1.28 mm | 1.3 mm | 1.23 mm | 1.25 mm |
| Bottom Bracket Height | 346 mm | 339.8 mm | 346.2 mm | 339.9 mm | 346.3 mm | 339.9 mm | 346.5 mm | 340 mm |
| Front Center | 747 mm | 748 mm | 789 mm | 789 mm | 825 mm | 826 mm | 862 mm | 862 mm |
| Rake | 44 mm | 45 mm | 43 mm | 44 mm | 43 mm | 44 mm | 43 mm | 44 mm |
| Trail | 128 mm | 131 mm | 129.1 mm | 132 mm | 129.2 mm | 132.6 mm | 130 mm | 132.7 mm |
| Stack | 600.7 mm | 604.2 mm | 614 mm | 617.7 mm | 627.3 mm | 631.1 mm | 640.7 mm | 644.6 mm |
| Reach | 426.1 mm | 421 mm | 461 mm | 456 mm | 490.9 mm | 486 mm | 520.8 mm | 516 mm |
| Top Tube Length | 544.5 mm | 546.1 mm | 593.5 mm | 595.2 mm | 626.5 mm | 628.3 mm | 659.7 mm | 661.5 mm |
| Seat Tube Angle | 78.9 ° | 78.3 ° | 77.8 ° | 77.3 ° | 77.8 ° | 77.3 ° | 77.8 ° | 77.3 ° |
| Seat Tube Length | 365 mm | 365 mm | 395 mm | 395 mm | 425 mm | 425 mm | 455 mm | 455 mm |
| Head Tube Angle | 64.7 ° | 64.2 ° | 64.6 ° | 64.2 ° | 64.6 ° | 64.2 ° | 64.6 ° | 64.2 ° |
| Head Tube Length | 90 mm | 90 mm | 105 mm | 105 mm | 120 mm | 120 mm | 135 mm | 135 mm |
| Chainstay Length | 434 mm | 432 mm | 434 mm | 432 mm | 434 mm | 432 mm | 434 mm | 432 mm |
| Wheelbase | 1180 mm | 1178 mm | 1221 mm | 1219 mm | 1257 mm | 1256 mm | 1294 mm | 1292 mm |
| Bottom Bracket Drop | 29 mm | 35 mm | 28 mm | 35 mm | 28 mm | 35 mm | 28 mm | 35 mm |
| Standover Height | 682 mm | 682 mm | 714 mm | 714 mm | 739 mm | 739 mm | 765 mm | 765 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
Model Overview
Linkin 135 Ultimate is a Bold Linkin model. Bold launched 18 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Trail bikes
The average weight for Trail bikes is 12.88 kg (28.4 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 13.9 kg (30.64 lbs), the Linkin 135 Ultimate model is a bit heavier than average. In conclusion, the average Trail bike weighs 7.92% less than Linkin 135 Ultimate.
Overview of components
Fork
The fork installed on this bike is the Fox Performance Elite Float 36 model. The travel on this model is 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Bold Linkin 135 Ultimate bike has the FOX NUDE 5T EVOL Trunnion model installed, and has a travel of 135mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on Linkin 135 Ultimate are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Bold Linkin 135 Ultimate has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
