Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 150mm -
Fork Öhlins RXF36
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bold Linkin 150 / Carbon HMX, Integrated Suspension Technology / IST VP, Vario Tech, Head angle and BB heigh / Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
Suspension Fork
Ohlins RXF36 m.2 Air, TTX-Technology HSC - LSC - LSR adjustable / 15x110mm Axle, 44mm offset / tapered steerer, 150mm travel
Rear Shock
FOX NUDE 5T EVOL Trunnion, Custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend, Custom large Air volume / DPS / Reb. Adj. T185X55mm / Travel 150-100-Lockout
Drivetrain
Rear Derailleur
Shimano XT RD-M8100 SGS, Shadow Plus / 12 Speed
Shift Levers
Shimano XT SL-M8100-IR / Rapidfire Plus, Ispec EV clamp
Cassette
Shimano XT CS-M8100-12 / 10-51 T
Crank
Shimano XT FC-M8120-1 / Hollowtech 2 / 32T
Bottom Bracket
Shimano SM-BB71-41A / shell 41x92mm
Chain
Shimano XT CN-M8100
Chain Guide
Bold custom
Wheels
Rims
Syncros Revelstoke 1.5 6 Bolt, F: 15x110mm / R: 12x148mm, 30mm Tubeless ready rim 28H / XD Driver, Syncros Axle w/Removable Lever with Tool
Tires
Front: Maxxis Minion DHF / 2.5" / 60TPI Foldable, Tubeless Ready / EXO, Rear: Maxxis Minion DHF / 2.5" / 60TPI Foldable, Tubeless Ready / EXO
Brakes
Brakes
Shimano XT M8120 4 Piston Disc
Cockpit
Stem
Syncros AM 1.5, Syncros Cable Integration System, 4° rise / 7050 Alloy / 31.8mm / 1 1/8"
Handlebar
Syncros Hixon 1.5 Alloy 7050, Size S & M 15mm rise / Size L & XL 25mm rise, back sweep 8° / 780mm, Syncros Endurance lock-on grips
Headset
Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
Seat
Saddle
Syncros Tofino 1.5 Regular, Titanium rails
Seatpost
Syncros Duncan Dropper Post 1.5 34.9mm, Size S 170mm / Size M, L & XL 200mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.44 mm | 1.33 mm | 1.35 mm | 1.28 mm | 1.3 mm | 1.23 mm | 1.25 mm |
| Bottom Bracket Height | 346 mm | 339.8 mm | 346.2 mm | 339.9 mm | 346.3 mm | 339.9 mm | 346.5 mm | 340 mm |
| Front Center | 747 mm | 748 mm | 789 mm | 789 mm | 825 mm | 826 mm | 862 mm | 862 mm |
| Rake | 44 mm | 45 mm | 43 mm | 44 mm | 43 mm | 44 mm | 43 mm | 44 mm |
| Trail | 128 mm | 131 mm | 129.1 mm | 132 mm | 129.2 mm | 132.6 mm | 130 mm | 132.7 mm |
| Stack | 600.7 mm | 604.2 mm | 614 mm | 617.7 mm | 627.3 mm | 631.1 mm | 640.7 mm | 644.6 mm |
| Reach | 426.1 mm | 421 mm | 461 mm | 456 mm | 490.9 mm | 486 mm | 520.8 mm | 516 mm |
| Top Tube Length | 544.5 mm | 546.1 mm | 593.5 mm | 595.2 mm | 626.5 mm | 628.3 mm | 659.7 mm | 661.5 mm |
| Seat Tube Angle | 78.9 ° | 78.3 ° | 77.8 ° | 77.3 ° | 77.8 ° | 77.3 ° | 77.8 ° | 77.3 ° |
| Seat Tube Length | 365 mm | 365 mm | 395 mm | 395 mm | 425 mm | 425 mm | 455 mm | 455 mm |
| Head Tube Angle | 64.7 ° | 64.2 ° | 64.6 ° | 64.2 ° | 64.6 ° | 64.2 ° | 64.6 ° | 64.2 ° |
| Head Tube Length | 90 mm | 90 mm | 105 mm | 105 mm | 120 mm | 120 mm | 135 mm | 135 mm |
| Chainstay Length | 434 mm | 432 mm | 434 mm | 432 mm | 434 mm | 432 mm | 434 mm | 432 mm |
| Wheelbase | 1180 mm | 1178 mm | 1221 mm | 1219 mm | 1257 mm | 1256 mm | 1294 mm | 1292 mm |
| Bottom Bracket Drop | 29 mm | 35 mm | 28 mm | 35 mm | 28 mm | 35 mm | 28 mm | 35 mm |
| Standover Height | 682 mm | 682 mm | 714 mm | 714 mm | 739 mm | 739 mm | 765 mm | 765 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
Model Overview
Linkin 150 Pro is part of the Bold Linkin model. Bold released 18 bikes variations of this model so far. Take a sneak peek at all Bold Linkin bikes models from 2023, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro bikes
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, this doesn’t mean that if you spend less money on an Enduro bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Enduro bikes average weight
On a deeper look, we notice that the average weight of an Enduro bike is 14 kg (30.86 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 13.9 kg (30.64 lbs), the Linkin 150 Pro model is slightly lighter than average. In conclusion, the average Enduro bike weighs 0.72% more than Linkin 150 Pro.
Overview of components
Fork
The Linkin 150 Pro comes factory-installed with the Öhlins RXF36 fork. This has a travel range of 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Bold Linkin 150 Pro bike has the FOX NUDE 5T EVOL Trunnion model installed, and has a travel of 150mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The Linkin 150 Pro 2023 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Linkin 150 Pro has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
