Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 150mm -
Fork Fox Factory Float 36
-
Groupset XX1 Eagle AXS, SRAM -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bold Linkin 150 / Carbon HMX, Integrated Suspension Technology / IST VP, Vario Tech, Head angle and BB height / Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
Suspension Fork
FOX 36 Float Factory Grip 2 Air / Kashima, HSC - LSC - HSR- LSR adjustable / Kabolt 15x110mm axle, 44mm offset / tapered steerer, 150mm travel
Rear Shock
FOX NUDE 5T Factory EVOL Trunnion, Custom travel / geo adj. 3 modes: Lockout-Traction Control-Descend, Custom large Air volume / DPS / Kashima / Reb. Adj. Travel 150-100-Lockout / T185X55mm
Drivetrain
Rear Derailleur
SRAM XX1 Eagle AXS / 12 Speed, Wireless Electronic Shift System
Shift Levers
SRAM Eagle AXS Rocker Controller
Cassette
SRAM XX1 XG1299 / 10-52 T
Crank
SRAM XX1 Eagle, Carbon crankarm, DUB / 55mm CL / 32T
Bottom Bracket
SRAM DUB PF 92 MTB Wide / shell 41x92mm
Chain
SRAM CN XX1 Eagle
Chain Guide
Bold custom
Wheels
Rims
DT Swiss XMC 1501 Spline CL, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready Carbon rim 28H / XD Driver, Syncros Axle w/Removable Lever with Tool
Tires
Front: Maxxis Minion DHF / 2.5" / 60TPI Foldable, Tubeless Ready / EXO, Rear: Maxxis Minion DHF / 2.5" / 60TPI Foldable, Tubeless Ready / EXO
Brakes
Brakes
Shimano XTR M9120 4 Piston Disc
Cockpit
Handlebar
Syncros Hixon iC Carbon, Size S & M 15mm rise / Size L & XL 25mm rise, back sweep 8° / 780mm, Syncros Pro lock-on grips
Headset
Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
Seat
Saddle
Syncros Tofino Regular 1.0, Carbon rails
Seatpost
Syncros Duncan Dropper Post 1.5 34.9mm, Size S 150mm / Size M 170mm / Size L & XL 200mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.44 mm | 1.33 mm | 1.35 mm | 1.28 mm | 1.3 mm | 1.23 mm | 1.25 mm |
| Bottom Bracket Height | 346 mm | 339.8 mm | 346.2 mm | 339.9 mm | 346.3 mm | 339.9 mm | 346.5 mm | 340 mm |
| Front Center | 747 mm | 748 mm | 789 mm | 789 mm | 825 mm | 826 mm | 862 mm | 862 mm |
| Rake | 44 mm | 45 mm | 43 mm | 44 mm | 43 mm | 44 mm | 43 mm | 44 mm |
| Trail | 128 mm | 131 mm | 129.1 mm | 132 mm | 129.2 mm | 132.6 mm | 130 mm | 132.7 mm |
| Stack | 600.7 mm | 604.2 mm | 614 mm | 617.7 mm | 627.3 mm | 631.1 mm | 640.7 mm | 644.6 mm |
| Reach | 426.1 mm | 421 mm | 461 mm | 456 mm | 490.9 mm | 486 mm | 520.8 mm | 516 mm |
| Top Tube Length | 544.5 mm | 546.1 mm | 593.5 mm | 595.2 mm | 626.5 mm | 628.3 mm | 659.7 mm | 661.5 mm |
| Seat Tube Angle | 78.9 ° | 78.3 ° | 77.8 ° | 77.3 ° | 77.8 ° | 77.3 ° | 77.8 ° | 77.3 ° |
| Seat Tube Length | 365 mm | 365 mm | 395 mm | 395 mm | 425 mm | 425 mm | 455 mm | 455 mm |
| Head Tube Angle | 64.7 ° | 64.2 ° | 64.6 ° | 64.2 ° | 64.6 ° | 64.2 ° | 64.6 ° | 64.2 ° |
| Head Tube Length | 90 mm | 90 mm | 105 mm | 105 mm | 120 mm | 120 mm | 135 mm | 135 mm |
| Chainstay Length | 434 mm | 432 mm | 434 mm | 432 mm | 434 mm | 432 mm | 434 mm | 432 mm |
| Wheelbase | 1180 mm | 1178 mm | 1221 mm | 1219 mm | 1257 mm | 1256 mm | 1294 mm | 1292 mm |
| Bottom Bracket Drop | 29 mm | 35 mm | 28 mm | 35 mm | 28 mm | 35 mm | 28 mm | 35 mm |
| Standover Height | 682 mm | 682 mm | 714 mm | 714 mm | 739 mm | 739 mm | 765 mm | 765 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
About this model
Linkin 150 Ultimate is a Bold Linkin model. Bold launched 18 bikes of this model so far. Take a sneak peek at all Bold Linkin bikes models from 2023, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Enduro bikes
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Enduro bikes average weight
Enduro bikes have an average weight of 14 kg (30.86 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Linkin 150 Ultimate weighs 13 kg (28.66 lbs) and is a bit lighter than the average. In conclusion, the average Enduro bike weighs 7.69% more than Linkin 150 Ultimate.
Linkin 150 Ultimate components
Fork
The Linkin 150 Ultimate comes factory-installed with the Fox Factory Float 36 fork. This has a travel range of 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The shock that’s installed on this bike is FOX NUDE 5T Factory EVOL Trunnion, with a travel distance of 150mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When it comes to wheels, the Linkin 150 Ultimate bike is equipped with the 29″ carbon model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The Linkin 150 Ultimate has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Dropper post
A dropper post is included with the Linkin 150 Ultimate. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
