Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox Lyrik Ultimate
-
Groupset GX Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bold Linkin 150 / Carbon HMX, Integrated Suspension Technology / IST VP, Vario Tech, Head angle and BB height / Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
Suspension Fork
RockShox Lyrik Ultimate Air, Charger 3 Damper, HSC - LSC - LSR adjustable, Butter cups / 15x110mm Maxle Stealth, 44mm offset / Tapered steerer, 160mm travel
Rear Shock
RockShox NUDE 5 RLC3 Trunnion, SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend, Low Speed Ad.j / Debon Air / Reb. Adj. 185X55mm / Travel 150-100-Lockout
Drivetrain
Rear Derailleur
SRAM GX Eagle AXS 12 Speed, Wireless Electronic Shift System
Shift Levers
SRAM GX Eagle AXS Rocker Controller
Cassette
SRAM XG1275 / 10-52 T
Crank
SRAM GX Eagle DUB, 55mm CL / 32T
Bottom Bracket
SRAM DUB PF 92 MTB Wide / shell 41x92mm
Chain
SRAM CN GX Eagle
Chain Guide
Bold custom
Wheels
Rims
DT Swiss XM 1850 Spline 6 Bolt, F: 15x110mm / R: 12x148mm, 30mm Tubeless ready rim 28H / XD Driver, Syncros Axle w/Removable Lever with Tool
Tires
Front: Maxxis Minion DHF / 2.5" / 60TPI Foldable, Tubeless Ready / EXO, Rear: Maxxis Minion DHF / 2.5" / 60TPI Foldable, Tubeless Ready / EXO
Brakes
Brakes
Shimano XT M8120 4 Piston Disc
Cockpit
Handlebar
Syncros Hixon iC Carbon, Size S & M 15mm rise / Size L & XL 25mm rise, back sweep 8° / 780mm, Syncros Endurance lock-on grips
Headset
Syncros - Acros Angle adjust & Cable Routing HS System, Stainless / +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
Seat
Saddle
Syncros Tofino 1.5 Regular, Titanium rails
Seatpost
Syncros Duncan Dropper Post 1.5 34.9mm, Size S 170mm / Size M, L & XL 200mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.44 mm | 1.35 mm | 1.38 mm | 1.3 mm | 1.32 mm | 1.25 mm | 1.27 mm |
| Bottom Bracket Height | 349.3 mm | 343.1 mm | 349.4 mm | 343.1 mm | 349.4 mm | 343 mm | 349.5 mm | 343 mm |
| Front Center | 751 mm | 752 mm | 792 mm | 793 mm | 829 mm | 829 mm | 865 mm | 866 mm |
| Rake | 43 mm | 42 mm | 43 mm | 44 mm | 43 mm | 44 mm | 43 mm | 44 mm |
| Trail | 133 mm | 137 mm | 132.3 mm | 135 mm | 132.4 mm | 135.8 mm | 133 mm | 135.7 mm |
| Stack | 604 mm | 604.2 mm | 617.4 mm | 621 mm | 630.8 mm | 634.6 mm | 644.3 mm | 648.2 mm |
| Reach | 421.5 mm | 421 mm | 456.4 mm | 451.5 mm | 486.4 mm | 481.5 mm | 516.5 mm | 511.5 mm |
| Top Tube Length | 546 mm | 547.6 mm | 595.1 mm | 596.9 mm | 628.2 mm | 630 mm | 661.3 mm | 663.2 mm |
| Seat Tube Angle | 78.4 ° | 77.5 ° | 77.4 ° | 76.8 ° | 77.4 ° | 76.8 ° | 77.4 ° | 76.8 ° |
| Seat Tube Length | 365 mm | 365 mm | 395 mm | 395 mm | 425 mm | 425 mm | 455 mm | 455 mm |
| Head Tube Angle | 64.2 ° | 63.8 ° | 64.2 ° | 63.8 ° | 64.2 ° | 63.8 ° | 64.2 ° | 63.8 ° |
| Head Tube Length | 90 mm | 90 mm | 105 mm | 105 mm | 120 mm | 120 mm | 135 mm | 135 mm |
| Chainstay Length | 434 mm | 432 mm | 434 mm | 433 mm | 434 mm | 433 mm | 434 mm | 433 mm |
| Wheelbase | 1184 mm | 1182 mm | 1225 mm | 1224 mm | 1262 mm | 1260 mm | 1298 mm | 1297 mm |
| Bottom Bracket Drop | 25 mm | 31 mm | 25 mm | 31 mm | 25 mm | 32 mm | 25 mm | 32 mm |
| Standover Height | 688 mm | 688 mm | 719 mm | 719 mm | 745 mm | 745 mm | 771 mm | 771 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
About this model
Linkin LT is a Bold Linkin model. There are 18 bikes that carry this model name. Take a sneak peek at all Bold Linkin bikes models from 2023, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Enduro bikes average price
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, this doesn’t mean that if you spend less money on an Enduro bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
Bold Linkin LT 2023 bike is equipped with the RockShox Lyrik Ultimate fork, and has 160mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The Linkin LT has a rear shock with a travel of 150mm. The model RockShox NUDE 5 RLC3 Trunnion is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
As for the wheels, Bold Linkin LT 2023, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Dropper post
A dropper post is included with the Linkin LT. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
