Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 double butted crmo frame, replaceable hanger, rack / fender mounts, 68 mm BSA shell
Suspension Fork
4130 crmo, tapered double butted blades with fender / rack mounts
Drivetrain
Rear Derailleur
-
Front Derailleur
-
Shift Levers
-
Cassette
17T heat treated crmo cog, 1/2" x 11/128"
Crank
BOMBTRACK TAF19 alloy crank, 24 mm spindle, BOMBTRACK RIDGE alloy, narrow-wide, 42T, 1/2" x 11/128"
Bottom Bracket
BSA sealed BB, external cups
Chain
KMC X11 chain, 1/2" x 11/128", 98L
Pedals
WELLGO B109N flat pedal
Wheels
Front Hub
Front: BOMBTRACK TITLE-DISC sealed, 6-bolt disc hub, QR axle, Rear: BOMBTRACK TITLE-DISC sealed hub, 11-speed, 6-bolt disc, QR axle
Rear Hub
Front: BOMBTRACK TITLE-DISC sealed, 6-bolt disc hub, QR axle, Rear: BOMBTRACK TITLE-DISC sealed hub, 11-speed, 6-bolt disc, QR axle
Rims
Front: WTB ST i19 double wall, TCS 2.0, 32h, Rear: WTB ST i19 double wall, TCS 2.0, 32h
Tires
Front: KENDA FLINTRIDGE tire, 700C x 35C, Rear: KENDA FLINTRIDGE tire, 700C x 35C
Brakes
Brakes
TEKTRO MIRA post mount mechanic disc brakes with 160 mm rotors
Cockpit
Stem
BOMBTRACK ROAM forged alloy stem, -7°
Handlebar
BOMBTRACK CX-10 drop bar, 31.8 mm, 10° flare
Grips
BOMBTRACK CONTROL bar tape
Headset
FSA ORBIT MX sealed external aheadset, 1.1/8"
Seat
Saddle
BOMBTRACK Comp saddle
Seatpost
BOMBTRACK BEECH alloy seatpost, 27.2 mm x 300 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.48 mm | 1.51 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 579 mm | 589 mm | 609 mm | 624 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 81.3 mm | 74.8 mm | 70.9 mm | 64.5 mm |
| Stack | 506 mm | 532 mm | 561 mm | 595 mm |
| Reach | 355 mm | 365 mm | 380 mm | 395 mm |
| Top Tube Length | 511 mm | 529 mm | 553 mm | 578 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 510 mm | 540 mm | 580 mm |
| Head Tube Angle | 69.5 ° | 70.5 ° | 71 ° | 72 ° |
| Head Tube Length | 85 mm | 108 mm | 137 mm | 169 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheelbase | 984 mm | 994 mm | 1014 mm | 1030 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 741 mm | 769 mm | 797 mm | 834 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Arise 2 is part of the Bombtrack Arise model. There are 22 bikes that carry this model name. Take a sneak peek at all Bombtrack Arise bikes models from 2019, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Gravel bikes average weight
The average weight for Gravel bikes is 8.13 kg (17.92 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Bombtrack Arise 2 it’s weighing 10.5 kg (23.15 lbs). At this weight, is much heavier than average. In other words, this model is 29.15% heavier than the average Gravel bike.
Overview of components
Fork material
The fork on this bike is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
When leaving the production line, the Arise 2 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Arise 2 comes with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Arise 2 comes in 4 sizes, that range from 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, it won’t be difficult to find the right one for you.
