Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset microSHIFT, Deore -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 double butted crmo frame,heat treated front triangle, replaceable hanger, TA dropouts, rack / fender mounts, 68 mm BSA shell
Suspension Fork
4130 crmo, tapered double butted blades, TA, with rack / fender mounts
Drivetrain
Rear Derailleur
MICROSHIFT RD-M665M rear derailleur, clutch, medium cage
Front Derailleur
-
Shift Levers
SHIMANO DEORE SL-M6000 RAPIDFIRE PLUS shifter 1 x 10
Cassette
MICROSHIFT CS-H103 10-speed cassette, 11-42T
Crank
BOMBTRACK TAF19 aluminum crank, 24 mm spindle, BOMBTRACK RIDGE aluminum chainring, narrow-wide, 42T, 1/2" x 11/128", incl. Chainguard
Bottom Bracket
BSA sealed BB, external cups
Chain
KMC X10 chain, 1/2" x 11/128", 114L
Pedals
WELLGO B109N flat pedal
Wheels
Front Hub
Front: BOMBTRACK ORIGIN sealed disc hub, 12 x 100 mm thru-axle, Rear: BOMBTRACK ORIGIN sealed disc hub, 11-speed, 12 x 142 mm thru-axle
Rear Hub
Front: BOMBTRACK ORIGIN sealed disc hub, 12 x 100 mm thru-axle, Rear: BOMBTRACK ORIGIN sealed disc hub, 11-speed, 12 x 142 mm thru-axle
Rims
Front: BOMBTRACK TX20 double wall, i19, 32h, Rear: BOMBTRACK TX20 double wall, i19, 32h
Tires
Front: KENDA FLINTRIDGE tire, 700C x 40C, Rear: KENDA FLINTRIDGE tire, 700C x 40C
Brakes
Brakes
SHIMANO BR-M200 post mount hydraulic disc brake with 160 mm rotors
Cockpit
Stem
BOMBTRACK ROAM forged aluminum stem, -7°
Handlebar
BOMBTRACK Origin flat bar, 31.8 mm, 8° backsweep
Grips
BOMBTRACK LOCK 145 mm grips
Headset
NECO H282 sealed external aheadset, 1.1/8"
Seat
Saddle
BOMBTRACK COMP saddle
Seatpost
BOMBTRACK BEECH aluminum seatpost, 27.2 mm x 300 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.52 mm | 1.53 mm | 1.56 mm | 1.58 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm | 274 mm | 274 mm |
| Front Center | 598 mm | 608 mm | 630 mm | 647 mm | 669 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Trail | 75.8 mm | 65.9 mm | 65.9 mm | 62.7 mm | 62.7 mm |
| Stack | 525 mm | 553 mm | 579 mm | 608 mm | 636 mm |
| Reach | 351 mm | 365 mm | 378 mm | 390 mm | 403 mm |
| Top Tube Length | 514 mm | 536 mm | 557 mm | 579 mm | 600 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 69 ° | 70.5 ° | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 100 mm | 123 mm | 151 mm | 179 mm | 208 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1019 mm | 1029 mm | 1051 mm | 1069 mm | 1091 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 740 mm | 759 mm | 787 mm | 816 mm | 844 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Arise Geared is part of the Bombtrack Arise model. There are 22 bikes that carry this model name. Check out the entire range from 2020 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
The Arise Geared 2020 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Arise Geared comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Arise Geared comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
