Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b / 700c -
Groupset microSHIFT -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 double butted crmo, heat treated front triangle,TA sliding dropouts, rack / fender mounts,68 mm BSA BB shell
Suspension Fork
4130 crmo, TA, rack / fender mounts, internal hubdynamo cable routing
Drivetrain
Rear Derailleur
MICROSHIFT RD-M62L, long cage
Front Derailleur
MICROSHIFT FD-R552-B
Shift Levers
MICROSHIFT BS-M10 bar end shifter 2 x 10
Cassette
MICROSHIFT CS-H103 10-speed, 11-42T
Crank
BOMBTRACK AMES forged aluminium crank, 24 mm spindle, steel, subcompact, 46/30T
Bottom Bracket
BSA sealed BB, external cups
Chain
KMC X10 chain, 1/2" x 11/128", 114L
Pedals
-
Wheels
Front Hub
Front: KT dynamo hub, 6-bolt disc, Rear: BOMBTRACK ARC sealed disc hub, 11-speed, 6 bolt disc
Rear Hub
Front: KT dynamo hub, 6-bolt disc, Rear: BOMBTRACK ARC sealed disc hub, 11-speed, 6 bolt disc
Rims
Front: WTB ST i19 double wall, TCS 2.0, 32h, Rear: WTB ST i19 double wall, TCS 2.0, 32h
Tires
Front: XS - S 650B VEE TIRE SPEEDSTER 38-584M - XL 700C VEE TIRE SPEEDSTER 40-622, Rear: XS - S 650B VEE TIRE SPEEDSTER 38-584M - XL 700C VEE TIRE SPEEDSTER 40-622
Brakes
Brakes
TRP SPYRE C post mount mechanic disc brakes with 160 mm rotors
Cockpit
Stem
BOMBTRACK ROAM forged aluminium stem, -7°
Handlebar
BOMBTRACK CX-10 drop bar, 31.8 mm, 10° flare
Grips
BOMBTRACK ESCAPE bar tape
Headset
NECO H282 sealed external aheadset, 1.1/8"
Seat
Saddle
BOMBTRACK ORIGIN saddle
Seatpost
BOMBTRACK BEECH 27.2 mm x 300 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.46 mm | 1.52 mm | 1.54 mm | 1.55 mm |
| Front Center | 582 mm | 602 mm | 619 mm | 639 mm | 664 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Trail | 64 mm | 60 mm | 68 mm | 65 mm | 65 mm |
| Stack | 500 mm | 530 mm | 564 mm | 594 mm | 623 mm |
| Reach | 343 mm | 362 mm | 371 mm | 386 mm | 401 mm |
| Top Tube Length | 498 mm | 521 mm | 546 mm | 570 mm | 594 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 100 mm | 130 mm | 150 mm | 180 mm | 210 mm |
| Chainstay Length | 412 mm | 412 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 987 mm | 1008 mm | 1037 mm | 1057 mm | 1082 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 725 mm | 754 mm | 791 mm | 820 mm | 849 mm |
| Wheels | 650 | 650 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Arise Tour completes the Bombtrack Arise model. Bombtrack released 22 bikes variations of this model so far. Take a sneak peek at all Bombtrack Arise bikes models from 2021, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Touring bikes average price
If you want to purchase a solid Touring bike, it is important to know that the average cost is 1007$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Touring bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Touring bikes
The average weight for Touring bikes is 13.35 kg (29.43 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Bombtrack Arise Tour it’s weighing 14.7 kg (32.41 lbs). At this weight, is considerably heavier than average. In conclusion, the average Touring bike weighs 10.11% less than Arise Tour.
Arise Tour components
Fork material
When it comes to the fork, this bike has a steel one, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
The wheels on Arise Tour are the aluminum type. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
