Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Groupset microSHIFT -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 double butted aluminium, TA, fender mounts, 86.5 mm T47 BB shell
Suspension Fork
Full carbon, TA, 1.1/2'' - 1.1/8'', with fender / cage mounts
Drivetrain
Rear Derailleur
MICROSHIFT RD-M665M, clutch, medium cage
Front Derailleur
-
Shift Levers
MICROSHIFT SB-M110 DUAL CONTROL LEVER 1 x 11
Cassette
MICROSHIFT CS-HG113 11-speed, 11 - 46 T
Crank
BOMBTRACK LYER forged aluminium crank, direct mount interface (SRAM compatible),30 mm spindle
Bottom Bracket
BOMBTRACK T47 internal sealed BB for 30 mm spindle
Chain
KMC X11 chain, 1/2'' x 11/128'', 114L
Pedals
-
Wheels
Front Hub
BOMBTRACK ARC sealed hub, 6-bolt disc
Rear Hub
BOMBTRACK ARC sealed hub, 11-speed, 6-bolt disc
Rims
WTB ST i21 double wall, TCS 2.0, 32h
Tires
WTB HORIZON 650B x 47C
Brakes
Brakes
TRP Spyre C flat-mount disc brakes with 160 mm rotors
Cockpit
Stem
BOMBTRACK ROAM forged aluminium stem, -7°
Handlebar
BOMBTRACK CX-10 drop bar, 31.8 mm, 10° flare
Grips
BOMBTRACK COMMAND bar tape
Headset
Sealed integrated aheadset, 1.1/2'' - 1.1/8''
Seat
Saddle
BOMBTRACK DART saddle
Seatpost
BOMBTRACK BEECH aluminium seatpost, 27.2 mm x 400 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 6.827 mm | 7.107 mm | 7.48 mm | 7.827 mm | 8.147 mm |
| Front Center | 581 mm | 590 mm | 610 mm | 630 mm | 647 mm |
| Rake | 53 mm | 53 mm | 53 mm | 53 mm | 53 mm |
| Trail | 62 mm | 56 mm | 56 mm | 56 mm | 56 mm |
| Stack | 514 mm | 535 mm | 563 mm | 589 mm | 613 mm |
| Top Tube Length | 507 mm | 529 mm | 553 mm | 571 mm | 594 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 120 mm | 150 mm | 180 mm | 205 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 993 mm | 1002 mm | 1023 mm | 1043 mm | 1061 mm |
| Bottom Bracket Drop | 70 mm | 68 mm | 68 mm | 65 mm | 65 mm |
| Standover Height | 730 mm | 756 mm | 784 mm | 814 mm | 840 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
AUDAX AL completes the Bombtrack Audax model. Bombtrack released 10 bikes variations of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Endurance bikes
Our math shows that the average cost of a dependable Endurance bike is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Endurance bikes average weight
Endurance bikes weigh an average of 8.2 kg (18.08 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 10.4 kg (22.93 lbs), the AUDAX AL model is much heavier than average. In short, the average Endurance bike weight is 26.83% lower than this one.
AUDAX AL components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The AUDAX AL 2022 bike is equipped with aluminum wheels when leaving the factory. These wheels are less popular than 650b and 700c. However, 650c wheels have better acceleration, and can climb easier than 700c.
Brakes
For your safety, it is important to have quality breaks on your bike. Bombtrack AUDAX AL has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Bombtrack AUDAX AL bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
