Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset microSHIFT -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 double butted aluminium, TA, fender mounts, 86.5 mm T47 BB shell
Suspension Fork
Full carbon, TA, 1.1/2'' - 1.1/8'', with fender / cage mounts
Drivetrain
Rear Derailleur
MICROSHIFT RD-M665M, clutch, medium cage
Front Derailleur
-
Shift Levers
MICROSHIFT SB-M110 DUAL CONTROL LEVER 1 x 11
Cassette
MICROSHIFT CS-HG113 11-speed, 11 - 46 T
Crank
BOMBTRACK LYER forged aluminium crank, direct mount interface (SRAM compatible),30 mm spindle
Bottom Bracket
BOMBTRACK T47 internal sealed BB for 30 mm spindle
Chain
KMC X11 chain, 1/2'' x 11/128'', 114L
Pedals
-
Wheels
Front Hub
BOMBTRACK ARC sealed hub, 6-bolt disc
Rear Hub
BOMBTRACK ARC sealed hub, 11-speed, 6-bolt disc
Rims
WTB ST i21 double wall, TCS 2.0, 32h
Tires
Front: WTB HORIZON 650B x 47C, Rear: WTB HORIZON 650B x 47C
Brakes
Brakes
TRP Spyre C flat-mount disc brakes with 160 mm rotors
Cockpit
Stem
BOMBTRACK ROAM forged aluminium stem, -7°
Handlebar
BOMBTRACK CX-10 drop bar, 31.8 mm, 10° flare
Grips
BOMBTRACK COMMAND bar tape
Headset
Sealed integrated aheadset, 1.1/2'' - 1.1/8''
Seat
Saddle
BOMBTRACK DART saddle
Seatpost
BOMBTRACK BEECH aluminium seatpost, 27.2 mm x 400 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.4 mm | 1.44 mm | 1.46 mm | 1.48 mm |
| Front Center | 581 mm | 590 mm | 610 mm | 630 mm | 647 mm |
| Rake | 53 mm | 53 mm | 53 mm | 53 mm | 53 mm |
| Trail | 62 mm | 56 mm | 56 mm | 56 mm | 56 mm |
| Stack | 514 mm | 535 mm | 563 mm | 589 mm | 613 mm |
| Reach | 370 mm | 381 mm | 392 mm | 403 mm | 413 mm |
| Top Tube Length | 507 mm | 529 mm | 553 mm | 571 mm | 594 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 560 mm | 590 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 120 mm | 150 mm | 180 mm | 205 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 993 mm | 1002 mm | 1023 mm | 1043 mm | 1061 mm |
| Bottom Bracket Drop | 70 mm | 68 mm | 68 mm | 65 mm | 65 mm |
| Standover Height | 730 mm | 756 mm | 784 mm | 814 mm | 840 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
AUDAX AL is part of the Bombtrack Audax model. 10 bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Endurance bikes
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Endurance bikes average weight
Endurance bikes weigh an average of 8.2 kg (18.08 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Bombtrack AUDAX AL it’s weighing 10.4 kg (22.93 lbs). At this weight, is much heavier than average. In short, the average Endurance bike weight is 26.83% lower than this one.
AUDAX AL components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The AUDAX AL 2023 bike is equipped with aluminum wheels when leaving the factory. These wheels are less popular than 650b and 700c. However, 650c wheels have better acceleration, and can climb easier than 700c.
Brakes
When you want to stop the bike in time, the brakes are vital. The AUDAX AL has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Bombtrack AUDAX AL bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
