Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b / 29" -
Groupset Apex 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 double butted crmo, TA,rack / fender mounts, internal light cable routing,73 mm BSA BB shell
Suspension Fork
4130 crmo, double butted blades, TA, 1.1/2" - 1.1/8", fender / rack /triple cage mounts, internal hub dynamo cable routing
Drivetrain
Rear Derailleur
SRAM APEX 1, clutch, long cage
Front Derailleur
-
Shift Levers
SRAM Apex double tap 1 x 11
Cassette
SRAM PG-1130 11-speed, 11-42T
Crank
BOMBTRACK AMES forged aluminium crank, 24 mm spindle, aluminium, narrow-wide, 36T
Bottom Bracket
BSA sealed BB, external cups
Chain
KMC X11 chain, 1/2" x 11/128", 114L
Pedals
-
Wheels
Front Hub
Front: KT dynamo hub, 6-bolt disc, Rear: BOMBTRACK TAU sealed hub,11-speed, 6-bolt disc
Rear Hub
Front: KT dynamo hub, 6-bolt disc, Rear: BOMBTRACK TAU sealed hub,11-speed, 6-bolt disc
Rims
Front: WTB ST i23 double wall, TCS 2.0, 32h, Rear: WTB ST i23 double wall, TCS 2.0, 32h
Tires
Front: PANARACER GRAVELKING SK XS - S 48-584 /M - XL 50-622, tubeless ready, Rear: PANARACER GRAVELKING SK XS - S 48-584 /M - XL 50-622, tubeless ready
Brakes
Brakes
TRP SPYRE C mechanic disc brakes with 180 mm F / 160 mm R rotors
Cockpit
Stem
BOMBTRACK WANDER forged aluminium stem, +17°
Handlebar
BOMBTRACK BEYOND travel bar, 31.8 mm, 30° flare
Grips
BOMBTRACK COMMAND bar tape
Headset
Sealed external aheadset, 1.1/2" - 1.1/8"
Seat
Saddle
BOMBTRACK ORIGIN saddle
Seatpost
BOMBTRACK BEECH 27.2 mm x 400 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.542 mm | 1.56 mm | 1.594 mm | 1.648 mm | 1.642 mm |
| Front Center | 581 mm | 602 mm | 620 mm | 636 mm | 663 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 73 mm | 70 mm | 73 mm | 67 mm | 67 mm |
| Stack | 538 mm | 568 mm | 604 mm | 646 mm | 675 mm |
| Reach | 349 mm | 364 mm | 379 mm | 392 mm | 411 mm |
| Top Tube Length | 494 mm | 522 mm | 558 mm | 590 mm | 623 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 520 mm | 560 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 130 mm | 150 mm | 190 mm | 220 mm |
| Chainstay Length | 425 mm | 425 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1000 mm | 1021 mm | 1065 mm | 1082 mm | 1109 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 727 mm | 761 mm | 802 mm | 842 mm | 873 mm |
| Wheels | 650 | 650 | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Beyond 2 is a Bombtrack Beyond model. There are 19 bikes that carry this model name. Take a sneak peek at all Bombtrack Beyond bikes models from 2021, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Touring bikes average price
According to our calculations, the average cost of a Touring bike that is reliable is 1007$. However, you could also get a good Touring bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Touring bikes average weight
On a deeper look, we notice that the average weight of a Touring bike is 13.35 kg (29.43 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
slightly lighter than average, Beyond 2 has a weight of 13.2 kg (29.1 lbs). In short, the average Touring bike weight is 1.14% higher than this one.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Beyond 2 components
Fork material
The fork on this bike is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
The wheels on Beyond 2 are the aluminum type. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Bombtrack Beyond 2 has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
