Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 27.5" -
Groupset Apex 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 double butted crmo, TA, rack / fender mounts, internal light cable routing, 73 mm BSA BB shell
Suspension Fork
4130 crmo, double butted blades, TA, 1.1/2'' - 1.1/8'', fender / rack /, triple cage mounts, internal hub dynamo cable routing
Drivetrain
Rear Derailleur
SRAM APEX 1, clutch, long cage
Front Derailleur
-
Shift Levers
SRAM Apex double tap 1 x 11
Cassette
SRAM PG-1130 11-speed, 11 - 42 T
Crank
BOMBTRACK AMES forged aluminium crank, 24 mm spindle
Bottom Bracket
BSA sealed BB, external cups
Chain
KMC X11 chain, 1/2'' x 11/128'', 114L
Pedals
-
Wheels
Front Hub
KT dynamo hub, 6-bolt disc
Rear Hub
BOMBTRACK ARC sealed hub, 11-speed, 6-bolt disc
Rims
WTB ST i23 double wall, TCS 2.0, 32h
Tires
PANARACER GRAVELKING SK XS - S 48-584 /, M - XL 50-622, tubeless ready
Brakes
Brakes
TRP SPYRE C mechanic disc brakes with 180 mm F / 160 mm R rotors
Cockpit
Stem
BOMBTRACK WANDER forged aluminium stem, +17°
Handlebar
BOMBTRACK BEYOND travel bar, 31.8 mm, 30° flare
Grips
BOMBTRACK COMMAND bar tape
Headset
Sealed external aheadset, 1.1/2'' - 1.1/8''
Seat
Saddle
BOMBTRACK FUZZ
Seatpost
BOMBTRACK BEECH 27.2 mm x 400 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 6.329 mm | 6.682 mm | 7.106 mm | 7.6 mm | 7.941 mm |
| Front Center | 581 mm | 602 mm | 620 mm | 636 mm | 663 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 73 mm | 70 mm | 73 mm | 67 mm | 67 mm |
| Stack | 538 mm | 568 mm | 604 mm | 646 mm | 675 mm |
| Top Tube Length | 494 mm | 522 mm | 558 mm | 590 mm | 623 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 520 mm | 560 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 130 mm | 150 mm | 190 mm | 220 mm |
| Chainstay Length | 425 mm | 425 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1000 mm | 1021 mm | 1065 mm | 1082 mm | 1109 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 727 mm | 761 mm | 802 mm | 842 mm | 873 mm |
| Wheels | 27" | 27" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
BEYOND 2 completes the Bombtrack Beyond model. Bombtrack released 19 bikes variations of this model so far. Take a sneak peek at all Bombtrack Beyond bikes models from 2022, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Gravel bikes average weight
If we make a quick analysis of the average weight of a Gravel bike, we get 8.13 kg (17.92 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
BEYOND 2 weighs 13.2 kg (29.1 lbs) and is much heavier than the average. To sum up, it’s 62.36% heavier than the average weight of Gravel bikes.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
BEYOND 2 has a steel fork, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
As for the wheels, Bombtrack BEYOND 2 2022, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The BEYOND 2 has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
BEYOND 2 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
