Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b / 29" -
Groupset GX, microSHIFT -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 double butted crmo, TA,rack / fender mounts, internal light cable routing, 73 mm BSA BB shell
Suspension Fork
4130 crmo, double butted blades, TA, 1.1/2" - 1.1/8", fender / rack /triple cage mounts, internal hub dynamo cable routing
Drivetrain
Rear Derailleur
SRAM GX, long cage
Front Derailleur
Microshift FD-M612-B
Shift Levers
SRAM Apex double tap 2 x 10
Cassette
SRAM PG-1020 10-speed, 11-36T
Crank
BOMBTRACK AMES forged aluminium crank, 24 mm spindle, Aluminium / Steel, 40/28T
Bottom Bracket
BSA sealed BB, external cups
Chain
KMC X10 chain, 1/2" x 11/128", 114L
Pedals
-
Wheels
Front Hub
Front: BOMBTRACK GRAD sealed, 6-bolt disc hub, Rear: BOMBTRACK ARC sealed hub,11-speed, 6-bolt disc
Rear Hub
Front: BOMBTRACK GRAD sealed, 6-bolt disc hub, Rear: BOMBTRACK ARC sealed hub,11-speed, 6-bolt disc
Rims
Front: WTB ST i23 double wall, TCS 2.0, 32h, Rear: WTB ST i23 double wall, TCS 2.0, 32h
Tires
Front: WTB RANGER TCS LIGHT / FAST ROLLING XS - S 27.5" x 2.0" / M - XL 29" x 2.0", tubeless ready, Rear: WTB RANGER TCS LIGHT / FAST ROLLING XS - S 27.5" x 2.0" / M - XL 29" x 2.0", tubeless ready
Brakes
Brakes
TRP SPYRE C mechanic disc brakes with 180 mm F / 160 mm R rotors
Cockpit
Stem
BOMBTRACK WANDER forged aluminium stem, +17°
Handlebar
BOMBTRACK BEYOND travel bar, 31.8 mm, 30° flare
Grips
BOMBTRACK COMMAND bar tape
Headset
Sealed external aheadset, 1.1/2" - 1.1/8"
Seat
Saddle
BOMBTRACK ORIGIN saddle
Seatpost
BOMBTRACK BEECH 27.2 mm x 400 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.542 mm | 1.56 mm | 1.594 mm | 1.648 mm | 1.642 mm |
| Front Center | 581 mm | 602 mm | 620 mm | 636 mm | 663 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 73 mm | 70 mm | 73 mm | 67 mm | 67 mm |
| Stack | 538 mm | 568 mm | 604 mm | 646 mm | 675 mm |
| Reach | 349 mm | 364 mm | 379 mm | 392 mm | 411 mm |
| Top Tube Length | 494 mm | 522 mm | 558 mm | 590 mm | 623 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 520 mm | 560 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 130 mm | 150 mm | 190 mm | 220 mm |
| Chainstay Length | 425 mm | 425 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1000 mm | 1021 mm | 1065 mm | 1082 mm | 1109 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 727 mm | 761 mm | 802 mm | 842 mm | 873 mm |
| Wheels | 650 | 650 | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Beyond is a Bombtrack Beyond model. There are 19 bikes that carry this model name. You can easily view all of the Bombtrack Beyond bikes models from 2021, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Touring bikes average price
Our math shows that the average cost of a dependable Touring bike is 1007$. However, even if your budget is less than the average, you might still be able to get a top-quality Touring bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Touring bikes average weight
Touring bikes have an average weight of 13.35 kg (29.43 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 12.9 kg (28.44 lbs), Bombtrack bike is slightly lighter than average. In conclusion, the average Touring bike weighs 3.49% more than Beyond.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
The fork is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
The Beyond 2021 bike is equipped with aluminum wheels when leaving the factory. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Bombtrack Beyond is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Bombtrack Beyond bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
