Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 27.5" -
Travel Front 40mm -
Fork RockShox Rudy XPLR
-
Groupset Apex -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 double butted crmo, TA, rack / fender mounts, internal light cable routing, 73 mm BSA BB shell
Suspension Fork
ROCKSHOX RUDY suspension fork, 1.1/2" - 1.1/8", 40 mm travel
Drivetrain
Rear Derailleur
SRAM APEX 1, clutch, long cage
Front Derailleur
-
Shift Levers
SRAM Apex double tap 1 x 11
Cassette
SRAM PG-1130 11-speed, 11 - 42 T
Crank
BOMBTRACK AMES forged aluminium crank, 24 mm spindle
Bottom Bracket
BSA sealed BB, external cups
Chain
KMC X11 chain, 1/2'' x 11/128'', 114L
Pedals
-
Wheels
Front Hub
BOMBTRACK TAU sealed hub, 6-bolt disc
Rear Hub
BOMBTRACK TAU sealed hub, 11-speed, 6-bolt disc
Rims
WTB ST i23 double wall, TCS 2.0, 32h
Tires
Front: WTB VENTURE TCS LIGHT / FAST ROLLING XS - S 650B x 47C /, M - XL 700C x 50C, tubeless ready, Rear: WTB VENTURE TCS LIGHT / FAST ROLLING XS - S 650B x 47C /, M - XL 700C x 50C, tubeless ready
Brakes
Brakes
TRP SPYRE C mechanic disc brakes with 180 mm F / 160 mm R rotors
Cockpit
Stem
BOMBTRACK TRAMP forged aluminium stem, 3°
Handlebar
SEIDO TACKLE gravel bar, 31.8 mm, 25° flare
Grips
BOMBTRACK COMMAND bar tape
Headset
Sealed external aheadset, 1.1/2'' - 1.1/8''
Seat
Saddle
BOMBTRACK FUZZ
Seatpost
SEIDO BEECH 27.2 mm x 415 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.546 mm | 1.567 mm | 1.601 mm | 1.655 mm | 1.646 mm |
| Front Center | 581 mm | 602 mm | 620 mm | 636 mm | 663 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 75 mm | 72 mm | 75 mm | 69 mm | 69 mm |
| Stack | 538 mm | 569 mm | 605 mm | 647 mm | 675 mm |
| Reach | 348 mm | 363 mm | 378 mm | 391 mm | 410 mm |
| Top Tube Length | 493 mm | 522 mm | 558 mm | 590 mm | 624 mm |
| Seat Tube Angle | 74.8 ° | 74.3 ° | 73.3 ° | 72.8 ° | 72.3 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 520 mm | 560 mm |
| Head Tube Angle | 69.7 ° | 70.2 ° | 70.7 ° | 71.8 ° | 71.8 ° |
| Head Tube Length | 100 mm | 130 mm | 150 mm | 190 mm | 220 mm |
| Chainstay Length | 425 mm | 425 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1001 mm | 1022 mm | 1067 mm | 1083 mm | 1111 mm |
| Bottom Bracket Drop | 53 mm | 53 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 727 mm | 761 mm | 802 mm | 842 mm | 873 mm |
| Wheels | 27" | 27" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
BEYOND SUS is part of the Bombtrack Beyond model. 19 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Gravel bikes
Gravel bikes weigh an average of 8.13 kg (17.92 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
BEYOND SUS weighs 12.25 kg (27.01 lbs) and is much heavier than the average. In conclusion, the average Gravel bike weighs 50.68% less than BEYOND SUS.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
BEYOND SUS components
Fork
The fork installed on this bike is the RockShox Rudy XPLR model. The travel on this model is 40mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The wheels on BEYOND SUS are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The BEYOND SUS comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
