Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b -
Groupset SX Eagle, Truvativ Stylo -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 double butted crmo, TA,rack / fender mounts, Boost spacing,stealth dropper ready, 73 mm BSA BB shell*
Suspension Fork
BOMBTRACK BPS 4130 crmo, double butted blades, 1.1/2" - 1.1/8",fender / rack / triple cage mounts, internal hub dynamo cable routing
Drivetrain
Rear Derailleur
SRAM SX EAGLE, clutch, long cage
Front Derailleur
-
Shift Levers
SRAM SX-EAGLE 12-speed trigger shifter
Cassette
SRAM PG-1210 EAGLE 12-speed, 11-50T
Crank
TRUVATIV STYLO 6K aluminium crank, Boost DUB, SRAM EAGLE X-SYNC 2, narrow-wide, 30T
Bottom Bracket
SRAM DUB BSA 73 mm
Chain
SRAM NX EAGLE chain, 1/2" x 11/128", 118L
Pedals
-
Wheels
Front Hub
Front: BOMBTRACK GRAD Boost sealed hub, 6-bolt disc, Rear: BOMBTRACK GRAD Boost sealed hub, HG driver, 6-bolt disc
Rear Hub
Front: BOMBTRACK GRAD Boost sealed hub, 6-bolt disc, Rear: BOMBTRACK GRAD Boost sealed hub, HG driver, 6-bolt disc
Rims
Front: WTB ST i35 double wall, TCS 2.0, 32h, Rear: WTB ST i35 double wall, TCS 2.0, 32h
Tires
Front: WTB RANGER TCS TOUGH / FAST ROLLING 27.5" x 2.8",tubeless ready, Rear: WTB RANGER TCS TOUGH / FAST ROLLING 27.5" x 2.8",tubeless ready
Brakes
Brakes
SRAM LEVEL hydraulic disc brakes with 180 mm F / 160 mm R rotors
Cockpit
Stem
BOMBTRACK TRAMP forged aluminium stem, 3°
Handlebar
BOMBTRACK TRAIL flat bar, 31.8 mm, 9° backsweep, 4° upsweep, 7 mm rise
Grips
BOMBTRACK SCROLL grips
Headset
Sealed semi integrated / external aheadset, 1.1/2" - 1.1/8"
Seat
Saddle
BOMBTRACK ORIGIN saddle
Seatpost
BOMBTRACK YEW aluminium seatpost, 30.9 mm x 400 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.47 mm | 1.43 mm | 1.38 mm |
| Front Center | 665 mm | 688 mm | 713 mm | 741 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 83 mm | 83 mm | 83 mm | 83 mm |
| Stack | 621 mm | 630 mm | 644 mm | 653 mm |
| Reach | 409 mm | 429 mm | 449 mm | 474 mm |
| Top Tube Length | 577 mm | 602 mm | 626 mm | 654 mm |
| Seat Tube Angle | 74.8 ° | 74.5 ° | 74.5 ° | 74.4 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 69.3 ° | 69.3 ° | 69.3 ° | 69.3 ° |
| Head Tube Length | 100 mm | 110 mm | 125 mm | 135 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1110 mm | 1133 mm | 1158 mm | 1187 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 76 mm | 76 mm |
| Standover Height | 748 mm | 775 mm | 806 mm | 834 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Beyond+ belongs to the Bombtrack Beyond model. 19 bikes variations carry this model name so far. You can easily view all of the Bombtrack Beyond bikes models from 2021, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Touring bikes average price
According to our math, the average price for a trustworthy Touring bike is 1007$. However, even if your budget is less than the average, you might still be able to get a top-quality Touring bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Touring bikes
Touring bikes have an average weight of 13.35 kg (29.43 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
a bit heavier than average, Beyond+ has a weight of 14.4 kg (31.75 lbs). In short, the average Touring bike weight is 7.87% lower than this one.
Beyond+ components
Fork material
The fork on this bike is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
As for the wheels, Bombtrack Beyond+ 2021, has a aluminum model. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Beyond+ comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
