Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Groupset GX Eagle -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 double butted crmo tubing, with cage, rack and fender mounts, replaceable hanger, boost spacing, stealth dropper ready, 73 mm BSA shell
Suspension Fork
BOMBTRACK BPC full carbon disc fork, TA, 1.1/2" - 1.1/8" tapered steerer, with triple cage mounts
Drivetrain
Rear Derailleur
SRAM GX EAGLE rear derailleur, long cage
Front Derailleur
-
Shift Levers
SRAM GX-EAGLE 12-speed trigger shifter
Cassette
SRAM XG-1275 Eagle 12-speed cassette, 10-50T
Crank
SRAM GX EAGLE alloy crank, Boost DUB, SRAM GX EAGLE alloy, narrow-wide, 30T, 1/2" x 11/128"
Bottom Bracket
SRAM GXP DUB 73 mm
Chain
SRAM GX EAGLE chain, 1/2" x 11/128", 118L
Pedals
-
Wheels
Front Hub
Front: BOMBTRACK TRAIL sealed hub, 6-bolt disc, 15 x 110 mm thru-axle, Rear: BOMBTRACK TRAIL sealed hub, XD driver, 6-bolt disc, 12 x 148 mm thru-axle
Rear Hub
Front: BOMBTRACK TRAIL sealed hub, 6-bolt disc, 15 x 110 mm thru-axle, Rear: BOMBTRACK TRAIL sealed hub, XD driver, 6-bolt disc, 12 x 148 mm thru-axle
Rims
Front: WTB ST i45 TCS 2.0 double wall sleeved, 32h, Rear: WTB ST i40 TCS 2.0 double wall sleeved, 32h
Tires
Front: WTB RANGER TCS LIGHT folding tire, 29" x 3.0", Rear: WTB RANGER TCS LIGHT folding tire, 29" x 3.0"
Brakes
Brakes
SRAM GUIDE T hydraulic disc brakes with 180 mm F / 160 mm R rotors
Cockpit
Stem
BOMBTRACK TRAMP forged alloy stem, 3°
Handlebar
JONES H-BAR LOOP 710 travel bar, 31.8 mm, 710 mm
Grips
BOMBTRACK SHIFT 170 mm grips
Headset
FSA ORBIT ITA sealed semi integrated / external aheadset, 1.1/2" - 1.1/8"
Seat
Saddle
BOMBTRACK ORIGIN saddle
Seatpost
BOMBTRACK YEW alloy seatpost, 30.9 mm x 400 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.51 mm | 1.48 mm | 1.42 mm |
| Front Center | 670 mm | 693 mm | 718 mm | 747 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 98 mm | 98 mm | 98 mm | 98 mm |
| Stack | 627 mm | 636 mm | 650 | 659 mm |
| Reach | 401 mm | 421 mm | 440 mm | 465 mm |
| Top Tube Length | 579 mm | 604 mm | 628 mm | 656 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 110 mm | 125 mm | 135 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1117 mm | 1140 mm | 1165 mm | 1194 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 790 mm | 820 mm | 851 mm | 880 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Beyond+ ADV belongs to the Bombtrack Beyondplus model. Bombtrack released 7 bikes variations of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Touring bikes average price
According to our math, the average price for a trustworthy Touring bike is 1007$. However, even though the average price of a Touring bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Touring bikes average weight
Touring bikes have an average weight of 13.35 kg (29.43 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Bombtrack Beyond+ ADV it’s weighing 12.8 kg (28.22 lbs). At this weight, is slightly lighter than average. In conclusion, the average Touring bike weighs 4.3% more than Beyond+ ADV.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the Beyond+ ADV bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Bombtrack Beyond+ ADV bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
