Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 130mm -
Fork RockShox Pike Select
-
Groupset GX Eagle, Truvativ Descendant -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 double butted crmo, TA, rack / fender mounts, Boost spacing, stealth dropper ready, 73 mm BSA BB shell
Suspension Fork
ROCKSHOX PIKE SELECT suspension fork, 130 mm travel, 1.1/2" - 1.1/8"
Drivetrain
Rear Derailleur
SRAM GX EAGLE, clutch, long cage
Front Derailleur
-
Shift Levers
SRAM GX-EAGLE 12-speed trigger shifter
Cassette
SRAM XG-1275 EAGLE 12-speed, 10- 52T
Crank
SRAM DESCENDANT aluminium crank, Boost DUB, SRAM EAGLE X-SYNC 2, narrow-wide, 30T
Bottom Bracket
SRAM DUB BSA 73 mm
Chain
SRAM GX EAGLE chain, 1/2" x 11/128", 118L
Pedals
-
Wheels
Front Hub
Front: BOMBTRACK GRAD Boost sealed hub, 6-bolt disc, Rear: BOMBTRACK GON Boost sealed hub, XD driver, 6-bolt disc
Rear Hub
Front: BOMBTRACK GRAD Boost sealed hub, 6-bolt disc, Rear: BOMBTRACK GON Boost sealed hub, XD driver, 6-bolt disc
Rims
Front: WTB ST i29 double wall, TCS 2.0, 32h, Rear: WTB ST i29 double wall, TCS 2.0, 32h
Tires
Front: MAXXIS ARDENT 29 x 2.4" TLR, tubeless ready, Rear: MAXXIS ARDENT 29 x 2.4" TLR, tubeless ready
Brakes
Brakes
MAGURA TRAIL SPORT 4 piston front, 2 piston rear with 180 mm rotors
Cockpit
Stem
BOMBTRACK CHASE forged aluminium, 35 mm clamping diameter
Handlebar
BOMBTRACK ILLUSION flat bar, aluminium, 35 mm clamping diameter
Grips
BOMBTRACK RETURN 135 mm grips
Headset
Sealed semi integrated / external aheadset, 1.1/2" - 1.1/8"
Seat
Saddle
BOMBTRACK ORIGIN saddle
Seatpost
KS E20i dropper seatpost, 30.9 mm, 150 mm travel, 485 mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.38 mm | 1.36 mm |
| Bottom Bracket Height | 319 mm | 319 mm | 319 mm |
| Front Center | 721 mm | 741 mm | 750 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 114 mm | 114 mm | 110 mm |
| Stack | 606 mm | 615 mm | 623 mm |
| Reach | 429 mm | 446 mm | 459 mm |
| Top Tube Length | 604 mm | 629 mm | 644 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 430 mm | 460 mm | 500 mm |
| Head Tube Angle | 67 ° | 67 ° | 67.5 ° |
| Head Tube Length | 110 mm | 120 mm | 125 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1146 mm | 1166 mm | 1176 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm |
| Standover Height | 779 mm | 798 mm | 821 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
Cale is a Bombtrack Cale model. 7 bikes variations carry this model name so far. Check out the entire range from 2021 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Trail bikes
The average weight for Trail bikes is 12.98 kg (28.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 13.8 kg (30.42 lbs), Bombtrack bike is a bit heavier than average. In short, the average Trail bike weight is 6.32% lower than this one.
Cale components
Fork
Bombtrack Cale 2021 bike is equipped with the RockShox Pike Select fork, and has 130mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the Cale model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Cale comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
