Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Rival 1, FSA -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
COLUMBUS CROMOR double butted tubing, TA dropout, replaceable hanger, rack / fender mounts, 68 mm T47 shell
Suspension Fork
BOMBTRACK CX-52 full carbon disc fork, TA, 1.1/2" - 1.1/8" tapered steerer, with fender mounts
Drivetrain
Rear Derailleur
SRAM RIVAL 1 rear derailleur, long cage
Front Derailleur
-
Shift Levers
SRAM RIVAL 1 double tap 1 x 11
Cassette
SRAM PG-1130 11-speed cassette, 11-42T
Crank
FSA GOSSAMER PRO 386EVO alloy crank, FSA GOSSAMER alloy, narrow-wide, 40T, 1/2" x 11/128"
Bottom Bracket
FSA MEGA EVO T47 outboard BB for T47 x 68 mm
Chain
KMC X11 chain, 1/2" x 11/128", 114L
Pedals
-
Wheels
Front Hub
Front: BOMBTRACK ORIGIN sealed disc hub, 12 x 100 mm thru-axle, Rear: BOMBTRACK ORIGIN sealed disc hub, 11-speed, 12 x 142 mm thru-axle
Rear Hub
Front: BOMBTRACK ORIGIN sealed disc hub, 12 x 100 mm thru-axle, Rear: BOMBTRACK ORIGIN sealed disc hub, 11-speed, 12 x 142 mm thru-axle
Rims
Front: WTB ST i19 double wall, TCS 2.0, 32h, Rear: WTB ST i19 double wall, TCS 2.0, 32h
Tires
Front: WTB RIDDLER TCS LIGHT folding tire, 700C x 37C, Rear: WTB RIDDLER TCS LIGHT folding tire, 700C x 37C
Brakes
Brakes
TRP SPYRE C flat mount mechanic disc brakes with 160 mm F / 140 mm R rotors
Cockpit
Stem
BOMBTRACK ROAM forged alloy stem, -7°
Handlebar
BOMBTRACK CX-10 drop bar, 31.8 mm, 10° flare
Grips
BOMBTRACK COMMAND bar tape
Headset
FSA ORBIT ITA sealed semi integrated / external aheadset, 1.1/2" - 1.1/8"
Seat
Saddle
BOMBTRACK COMP saddle
Seatpost
BOMBTRACK BEECH alloy seatpost, 27.2 mm x 300 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.47 mm | 1.46 mm | 1.47 mm |
| Bottom Bracket Height | 289 mm | 289 mm | 289 mm | 289 mm |
| Front Center | 586 mm | 597 mm | 609 mm | 627 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 72.6 mm | 66 mm | 66 mm | 66 mm |
| Stack | 523 mm | 554 mm | 565 mm | 584 mm |
| Reach | 367 mm | 377 mm | 386 mm | 397 mm |
| Top Tube Length | 519 mm | 538 mm | 555 mm | 572 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 495 mm | 525 mm | 545 mm | 565 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 128 mm | 140 mm | 160 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 997 mm | 1008 mm | 1020 mm | 1038 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 767 mm | 796 mm | 809 mm | 829 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Hook 2 belongs to the Bombtrack Hook model. 24 bikes variations carry this model name so far. Take a sneak peek at all Bombtrack Hook bikes models from 2019, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Gravel bikes average weight
Gravel bikes have an average weight of 8.13 kg (17.92 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 10.3 kg (22.71 lbs), Bombtrack bike is much heavier than average. In short, the average Gravel bike weight is 26.69% lower than this one.
Hook 2 components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the Hook 2 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Bombtrack Hook 2 has Mechanical Disc brakes installed. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
