Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b -
Travel Front 40mm -
Fork MRP Baxter
-
Groupset Rival 1 -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 double butted, heat treated crmo frame, replaceable hanger, rack / fender mounts, 86.5 mm T47 shell
Suspension Fork
MRP BAXTER 40mm suspension fork, 1.1/2" - 1.1/8" tapered steerer
Drivetrain
Rear Derailleur
SRAM RIVAL 1 rear derailleur, clutch, long cage
Front Derailleur
-
Shift Levers
SRAM RIVAL double tap 1 x 11, including left shifter for optional dropper routing
Cassette
SRAM PG-1130 11-speed cassette, 11-42T
Crank
BOMBTRACK LYER forged aluminum crank, direct mount interface, 30 mm spindle, CNC machined aluminum, narrow-wide, 38T, 1/2" x 11/128"
Bottom Bracket
T47 sealed BB for 30 mm spindle
Chain
KMC X11 chain, 1/2" x 11/128", 114L
Pedals
-
Wheels
Front Hub
Front: BOMBTRACK ORIGIN sealed disc hub, 12 x 100 mm thru-axle, Rear: BOMBTRACK ORIGIN sealed disc hub, 11-speed, 12 x 142 mm thru-axle
Rear Hub
Front: BOMBTRACK ORIGIN sealed disc hub, 12 x 100 mm thru-axle, Rear: BOMBTRACK ORIGIN sealed disc hub, 11-speed, 12 x 142 mm thru-axle
Rims
Front: WTB ST Light i25 double wall, TCS, 32h, Rear: WTB ST Light i23 double wall, TCS, 32h
Tires
Front: WTB RANGER TCS LIGHT folding tire 27.5" x 2.25", Rear: WTB RANGER TCS LIGHT folding tire 27.5" x 2.0"
Brakes
Brakes
SRAM RIVAL hydraulic disc brakes with 180 mm F / 160 mm R rotors
Cockpit
Stem
RITCHEY WCS TRAIL forged aluminum stem, 0°
Handlebar
RITCHEY WCS VENTUREMAX travel bar, 31.8 mm, 6° backsweep, 24° flare
Grips
RITCHEY WCS PAVE bar tape
Headset
FSA NO.21/12B/44 sealed external aheadset, 1.1/2" - 1.1/8"
Seat
Saddle
BOMBTRACK COMP saddle
Seatpost
KS E30i dropper seatpost, 27.2 mm, S / M: 65 / 390 mm, L: 100 / 400 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.54 mm | 1.56 mm |
| Front Center | 605 mm | 615 mm | 622 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 77.5 mm | 72.6 mm | 66.1 mm |
| Stack | 564 mm | 586 mm | 609 mm |
| Reach | 371 mm | 381 mm | 391 mm |
| Top Tube Length | 550 mm | 567 mm | 584 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 465 mm | 495 mm | 525 mm |
| Head Tube Angle | 70.3 ° | 71 ° | 72 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1017 mm | 1027 mm | 1034 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 761 mm | 777 mm | 803 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Hook ADV is part of the Bombtrack Hook model. Bombtrack launched 24 bikes of this model so far. Take a sneak peek at all Bombtrack Hook bikes models from 2020, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Hook ADV components
Fork
The MRP Baxter is included from the factory. It has a travel distance of 40mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The Hook ADV 2020 bike is equipped with aluminum wheels when leaving the factory. After 700c wheels, 650b is the second most popular choice for road bikes. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Nothing is more important on a bike than its ability to brake properly. Bombtrack Hook ADV is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
A dropper post is included with the Hook ADV. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
